Yaskawa CIMR-LE - Manual (Página 68)

3.7 Cableado del circuito principal
68 YASKAWA SISP YAIL1E 01A YASKAWA Variador CA L1000E Manual técnico
2A0031
R/L1, S/L2, T/L3
10
(8)
2.5 a 16
(12 a 6)
M4
1.2 a 1.5
(10.6 a 13.3)
U/T1, V/T2, W/T3
10
(8)
2.5 a 16
(12 a 6)
–, +1, +2 –
6.0 a 16
(10 a 6)
B1, B2 –
4.0 a 6.0
(12 a 10)
10
(8)
6.0 a 10
(10 a 8)
M5
2 a 2.5
(17.7 a 22.1)
2A0041
R/L1, S/L2, T/L3
16
(6)
2.5 a 16
(12 a 6)
M4
1.2 a 1.5
(10.6 a 13.3)
U/T1, V/T2, W/T3
16
(6)
2.5 a 16
(12 a 6)
–, +1, +2 –
16
(6)
B1, B2 –
4.0 a 6.0
(12 a 10)
10
(8)
6.0 a 10
(10 a 8)
M5
2 a 2.5
(17.7 a 22.1)
2A0059
R/L1, S/L2, T/L3
25
(4)
16 a 25
(6 a 4)
M6
4 a 6
(35.4 a 53.1)
U/T1, V/T2, W/T3
25
(4)
16 a 25
(6 a 4)
–, +1, +2 –
16 a 25
(6 a 4)
B1, B2 –
6.0 a 10
(10 a 6)
M5
2 a 2.5
(17.7 a 22.1)
16
(6)
10 a 16
(8 a 6)
M6
4 a 6
(35.4 a 53.1)
2A0075
R/L1, S/L2, T/L3
35
(3)
6.0 a 35
(10 a 2)
M8
9 a 11
(79.7 a 97.4)
U/T1, V/T2, W/T3
35
(3)
6.0 a 35
(10 a 2)
–, +1, +2 –
16 a 25
(4 a 3)
B1, B2 –
10 a 16
(8 a 6)
M5
2 a 2.5
(17.7 a 22.1)
16
(6)
16 a 25
(6 a 4)
M6
4 a 6
(35.4 a 53.1)
2A0094
R/L1, S/L2, T/L3
35
(2)
6.0 a 35
(10 a 2)
M8
9 a 11
(79.7 a 97.4)
U/T1, V/T2, W/T3
16  2P
(6  2P)
6.0 a 35
(10 a 2)
–, +1, +2 – 25 a 35
(3 a 2)
B1, B2 –
16
(6)
M5
2 a 2.5
(17.7 a 22.1)
16
(6)
16 a 25
(6 a 4)
M6
4 a 6
(35.4 a 53.1)
2A0106
R/L1, S/L2, T/L3
70
(1/0)
6.0 a 50
(10 a 1/0)
M8
9 a 11
(79.7 a 97.4)
U/T1, V/T2, W/T3
70
(1/0)
6.0 a 50
(10 a 1/0)
–, +1 –
35 a 50
(2 a 1/0)
B1, B2 –
16 a 50
(6 a 1/0)
16
(6)
16 a 25
(6 a 4)
Modelo de variador Terminal
Tamaño del cable
recomendado
mm 2 (AWG, kcmil)
Rango de hilo
mm 2 (AWG, kcmil)
Tamaño de los
tornillos
Torque de apriete
N•m (lb.in)
