D.3 estándares ul y csa – Yaskawa CIMR-AU 200V Manual del usuario
Página 787
Modelo de
variador
Terminal
Calibre recomendado
AWG, kcmil
Rango de cable
AWG, kcmil
Tamaño de
los
tornillos
Torque de ajuste
N·m (lb.in.)
4A0072
R/L1, S/L2, T/L3
3
4 a 3
M8
9 a 11
(79.7 a 97.4)
U/T1, V/T2, W/T3
3
4 a 3
⊖, ⊕1
–
4 a 1
B1, B2
–
6 a 3
6
6
4A0088
R/L1, S/L2, T/L3
2
3 a 1/0
M8
9 a 11
(79.7 a 97.4)
U/T1, V/T2, W/T3
2
3 a 1/0
⊖, ⊕1
–
3 a 1/0
⊕3
–
6 a 1/0
4
6 a 4
4A0103
R/L1, S/L2, T/L3
1/0
2 a 1/0
M8
9 a 11
(79.7 a 97.4)
U/T1, V/T2, W/T3
1
2 a 1/0
⊖, ⊕1
–
3 a 1/0
⊕3
–
4 a 1/0
4
6 a 4
4A0139
R/L1, S/L2, T/L3
3/0
1/0 a 4/0
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
2/0
1/0 a 4/0
⊖, ⊕1
–
1/0 a 4/0
⊕3
–
3 a 4/0
4
4
4A0165
R/L1, S/L2, T/L3
4/0
3/0 a 4/0
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
4/0
3/0 a 4/0
⊖, ⊕1
–
1 a 4/0
⊕3
–
1/0 a 4/0
4
4 a 2
4A0208
R/L1, S/L2, T/L3
300
2 a 300
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
300
2 a 300
⊖, ⊕1
–
1 a 250
⊕3
–
3 a 3/0
4
4 a 300
4A0250
R/L1, S/L2, T/L3
400
1 a 600
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
400
1/0 a 600
⊖, ⊕1
–
3/0 a 600
⊕3
–
1 a 325
2
2 a 350
4A0296
R/L1, S/L2, T/L3
500
2/0 a 600
M12
32 a 40
(283 a 354)
U/T1, V/T2, W/T3
500
2/0 a 600
⊖, ⊕1
–
3/0 a 600
⊕3
–
1 a 325
M10
18 a 23
(159 a 204)
2
2 a 350
M12
32 a 40
(283 a 354)
4A0362
R/L1, S/L2, T/L3
4/0 × 2P
3/0 a 600
M12
32 a 40
(283 a 354)
U/T1, V/T2, W/T3
4/0 × 2P
3/0 a 600
⊖, ⊕1
–
4/0 a 600
⊕3
–
3/0 a 600
M10
18 a 23
(159 a 204)
1
1 a 350
M12
32 a 40
(283 a 354)
4A0414
R/L1, S/L2, T/L3
300 × 2P
4/0 a 300
M12
32 a 40
(283 a 354)
U/T1, V/T2, W/T3
300 × 2P
4/0 a 300
⊖, ⊕1
–
3/0 a 300
⊕3
–
3/0 a 300
1
1 a 3/0
