211 TNC 410, TNC 426, TNC 430 de HEIDENHAIN
N210 I+35 J+50 *
N220 G01 G42 X+10 Y+50 *
N230 G02 X+10 *
N240 G98 L0 *
N250 G98 L2 *
N260 I+65 J+50 *
N270 G01 G42 X+90 Y+50 *
N280 G02 X+90 *
N290 G98 L0 *
N300 G98 L3 *
N310 G01 G41 X+27 Y+50 *
N320 Y+58 *
N330 X+43 *
N340 Y+42 *
N350 X+27 *
N360 G98 L0 *
N370 G98 L4 *
N380 G01 G41 X+65 Y+42 *
N390 X+57 *
N400 X+65 Y+58 *
N410 X+73 Y+42 *
N420 G98 L0 *
N999999 %C21 G71 *
Subprograma 2 del contorno: Cajera derecha
Subprograma 3 del contorno: Isla rectangular izquierda
Subprograma 4 del contorno: Isla triangular derecha
8.7 Ciclos SL gr
upo II (ex
cept
o
TNC 41
0)
