282 9440572990 Rev C
Comunicación PROFIBUS DECS-250N
Nombre de Instancia
Inst.
#
Tipo L E Nombre Clave Unidad Rango
Consignas FCR 69 UINT32 L/E
ExcCurPrepos
Mode2_GG
Sin
Unidad Mantener=0 Liberar=1
Consignas FCR 69 UINT32 L/E
ExcCurPrepos
Mode3_GG
Sin
Unidad Mantener=0 Liberar=1
Consignas FCR 70 Float L/E
ExcCur
TraverseRate_GG
Seg
10 - 200
Consignas FCR 70 Float L/E ExcCurSetpoint_GG Amp
0 - 12
Consignas FCR 70 Float L/E
ExcCurMinSetpoint
Limit_GG
%
0 - 120
Consignas FCR 70 Float L/E
ExcCurMaxSetpoint
Limit_GG
%
0 - 120
Consignas FCR 70 Float L/E
ExcCur
Preposition1_GG
Amp
0 - 12
Consignas FCR 70 Float L/E
ExcCur
Preposition2_GG
Amp
0 - 12
Consignas FCR 70 Float L/E
ExcCur
Preposition3_GG
Amp
0 - 12
Consignas FVR 71 UINT32 L/E
ExcVolPrepos
Mode1_GG
Sin
Unidad Mantener=0 Liberar=1
Consignas FVR 71 UINT32 L/E
ExcVolPrepos
Mode2_GG
Sin
Unidad Mantener=0 Liberar=1
Consignas FVR 71 UINT32 L/E
ExcVolPrepos
Mode3_GG
Sin
Unidad Mantener=0 Liberar=1
Consignas FVR 72 Float L/E ExcVolTraverseRate_GG Seg
10 - 200
Consignas FVR 72 Float L/E ExcVolSetpoint_GG V
0 - 75
Consignas FVR 72 Float L/E
ExcVolMinSetpoint
Limit_GG
%
0 - 150
Consignas FVR 72 Float L/E
ExcVolMaxSetpoint
Limit_GG
%
0 - 150
Consignas FVR 72 Float L/E
ExcVol
Preposition1_GG
V
0 - 75
Consignas FVR 72 Float L/E
ExcVol
Preposition2_GG
V
0 - 75
Consignas FVR 72 Float L/E
ExcVol
Preposition3_GG
V
0 - 75
Consignas VAR 73 UINT32 L/E
GenVarPrepos
Mode1_GG
Sin
Unidad Mantener=0 Liberar=1
Consignas VAR 73 UINT32 L/E
GenVarPrepos
Mode2_GG
Sin
Unidad Mantener=0 Liberar=1
Consignas VAR 73 UINT32 L/E
GenVarPrepos
Mode3_GG
Sin
Unidad Mantener=0 Liberar=1
Consignas VAR 74 Float L/E
SysOptionFineAdjust
Band_GG
%
0 - 30
Consignas VAR 74 Float L/E
GenVarTraverse
Rate_GG
Seg
10 - 200
Consignas VAR 74 Float L/E GenVarSetpoint_GG kvar
0 – 41.57
Consignas VAR 74 Float L/E
GenVarMinSetpoint
Limit_GG
%
-100 - 100
Consignas VAR 74 Float L/E
GenVarMaxSetpoint
Limit_GG
%
-100 - 100
Consignas VAR 74 Float L/E
GenVar
Preposition1_GG
kvar
0 – 41.57
Consignas VAR 74 Float L/E
GenVar
Preposition2_GG
kvar
0 – 41.57
Consignas VAR 74 Float L/E
GenVar
Preposition3_GG
kvar
0 – 41.57
Consignas PF 75 UINT32 L/E
GenPfPrepos
Mode1_GG
Sin
Unidad Mantener=0 Liberar=1
Consignas PF 75 UINT32 L/E
GenPfPrepos
Mode2_GG
Sin
Unidad Mantener=0 Liberar=1
Consignas PF 75 UINT32 L/E
GenPfPrepos
Mode3_GG
Sin
Unidad Mantener=0 Liberar=1
