InputBuffer.Under Excitation Limit ---> Or1.Input2
InputBuffer.Stator Current Limit ---> Or1.Input3
InputBuffer.Volts per Hz Limit ---> Or1.Input4
InputBuffer.Setpoint High Limit ---> Or2.Input1
InputBuffer.Setpoint Low Limit ---> Or2.Input2
Layer1.Or1.Output ---> Or3.Input2
Layer1.Or2.Output ---> Or3.Input3
InputBuffer.Under Freq Limit ---> Or3.Input4
Layer1.Mux3.Output2 ---> Or4.Input1
InputBuffer.Failed To Build Up ---> Or4.Input2
InputBuffer.EDM Open ---> Or4.Input3
InputBuffer.EDM Short ---> Or4.Input4
InputBuffer.Gen Over Voltage ---> Or5.Input1
InputBuffer.Gen Under Voltage ---> Or5.Input2
InputBuffer.Loss of Field ---> Or5.Input3
InputBuffer.Volts per Hz ---> Or5.Input4
InputBuffer.Field Over Temp ---> Or6.Input1
InputBuffer.Field Over Voltage ---> Or6.Input2
InputBuffer.Field Over Current ---> Or6.Input3
Layer1.Mux4.Output1 ---> Or6.Input4
InputBuffer.Contact Switch 10 ---> Not2.Input
Layer1.Mux1.Output2 ---> Not3.Input
Layer1.Mux3.Output1 ---> Not4.Input



=====> DESTINATION (DESTINO): Layer2

InputBuffer.Contact Switch 3 ---> Mux1.Input
Layer1.Not2.Output ---> Mux2.Input
Layer1.Or3.Output ---> Mux3.Input
Layer2.Mux3.Output2 ---> Or1.Input1
Layer2.Or1.Output ---> Or2.Input1
Layer1.Or4.Output ---> Or2.Input2
Layer1.Or5.Output ---> Or2.Input3
Layer1.Or6.Output ---> Or2.Input4
Layer2.Mux1.Output1 ---> Not1.Input
Layer2.Mux1.Output3 ---> Not2.Input

=====> DESTINATION (DESTINO): Layer3

Layer2.Not2.Output ---> And1.Input1
InputBuffer.Contact Switch 9 ---> And1.Input2
InputBuffer.Volts per Hz Limit ---> Or1.Input1
InputBuffer.Field Over Current ---> Or1.Input2

=====> DESTINATION (DESTINO): Layer4

Layer3.Or1.Output ---> Mux1.Input

=====> DESTINATION (DESTINO): OutputBuffer

InputBuffer.Start ---> Start
InputBuffer.Stop ---> Stop
Layer2.Not1.Output ---> Parallel
InputBuffer.Contact Switch 2 ---> Pre Position 2
InputBuffer.AVR ---> AVR
InputBuffer.FCR ---> FCR
Layer2.Mux1.Output2 ---> Pre Position 1
InputBuffer.Raise ---> Raise

9369772990 Rev R

Lógica programable del DECS-400

A-41
