MODO DE OPERAR
4/21/99
Command THC (X-Y) Manual de instrucciones 4-5
Figura 4-3 Pantallas de visualización del control pendiente
Pantalla de operación automática Pantalla de operación manual
Pantalla de diagnóstico B
Pantalla de modo remoto Pantalla del modo de mantenimiento
Pantalla de configuración A
Set Arc Volts 130.0
Actual Arc Volts 0.0
Set Cut Height 0.100 in
Pierce Delay 0.200sec
Retract FULL
IHS RUN
MANUAL POSITION
Actual Arc Volts 0.0
Set Cut Height Manual
Pierce Delay 0.000sec
Retract 2.500 in
IHS RUN
PRE-CUT PARAMETERS
OPR SCRN for Operator Menu
MISC PARAMETERS
CUTTING PARAMETERS
Pierce Height Factor (%) 100
Stall Force (1-10) 2
IHS Speed (1-10) 6
Nozzle Contact Active ON
Preflow During IHS OFF
Accel Delay (0-9 sec) 0.15
Auto Kerf ON
Homing Speed (1-10) 8
Inch or Metric Units inch
Retract delay (0-1 sec) 0.10
Press 'Shift B' to Begin Test
Upper Limit Switch OK
Lower Limit Switch OK
Lifter Type 2
Interface Rev G. 0 CS=c646
Real Time Rev G.0 CS=763a
DIAGNOSTIC
OPR SCRN For Operator Screen
REMOTE MODE
Consumable Change Only
Insure Plasma Safety
See Manual
MAINTENANCE MODE
MAINT Key to Resume
