- Site Controller Il - versión 2.2 y posteriores
- Redes de tarjetas de crédito y débito
- Interface de bombas
- Table of Contents
- 1 Introducción
- 2 Site Controller II
- Generalidades del sistema
- La impresora de registros
- Terminales
- Problemas de respuesta del sistema
- Sesiones de comandos
- Cómo realizar un inicio de sesión
- Cómo realizar un fin de sesión
- Fin de sesión automático
- Cómo cambiar un código de inicio de sesión
- Cómo introducir comandos y datos
- 1. Escriba PRINT DATE y .
- 2. El SCII mostrará la fecha.
- 3. Aparecerá la petición de comando.
- 1. Escriba LOAD DATE.
- 2. Introduzca el mes.
- 3. Introduzca el día.
- 4. Introduzca el año.
- 5. Introduzca la hora.
- 6. Introduzca los minutos.
- 7. El SCII mostrará la fecha y la hora.
- 8. Luego aparecerá la petición de comando.
- Cómo usar opciones con los comandos
- Cómo introducir múltiples bloques de información
- Cómo verificar los comandos
- Cómo usar rangos con los comandos
- Un método abreviado para introducir datos
- Cómo usar comandos en disco
- Redirección de la entrada al, y salida del, comando
- La impresora de registros
- Caracteres de control del teclado
- El comando HELP
- 3 Usuarios
- 4 Recibos, mensajes y fecha
- La fecha y hora
- LOAD DATE (LO DA)
- A* LOAD DATE ø
- Month? 1 ø
- Day of month? 31 ø
- Year? 97 ø
- Hour? 11 ø
- Minute? 40 ø
- Tues 1/31/97 11:40AM, Trans=57, Seq=624 SCIIv2.2
- A*
- PRINT DATE (P DA)
- A* PRINT DATE ø
- Tues 1/31/97 11:40AM, Trans=57, Seq=624 SCIIv2.2
- A*
- LOAD HEADING (LO H)
- A* LOAD HEADING ø
- Line number? 1 ø
- Heading line? SMITTY’S STATION ø
- Line number? 2 ø
- Heading line? 10 MAIN STREET ø
- Line number? 3 ø
- Heading line? SMITH,, WA 98000 ø
- Line number? 11 ø
- Footing line? THANK YOU ø
- Line number? 12 ø
- Footing line? PLEASE COME AGAIN ø
- Line number? 0 ø
- Form feed length? 5 ø
- Line number? ø
- A*
- Form feed length is in lines.
- The user typed two commas on the third heading line. One comma will be printed on the receipt.
- LOAD HEADING (LO H)
- A* LOAD HEADING ø
- Line number? 1 ø
- Heading line? {SMITTY’S STATION} ø
- Line number? 11 ø
- Footing line? THANK YOU~ ø
- Line number? 12 ø
- Footing line? THANK YOU ø
- Line number? ø
- A*
- PRINT HEADING (P H)
- A* PRINT HEADING ø
- N. Heading
- 0 5 BLANK LINES AT END
- 1 SMITTY’S STATION
- 2 10 MAIN STREET
- 3 SMITH, WA 98000
- 11 THANK YOU
- 12 PLEASE COME AGAIN
- A*
- REMOVE HEADING (REM H)
- A* REMOVE HEADING ø
- Line number? 2 ø
- A*
- LOAD MESSAGES (LO ME)
- A* LOAD MESSAGE;C ø
- Message number? 1 ø
- Display in sec? 2 ø
- Message? TRY A HOT SANDWICH ø
- Message number? 2 ø
- Display in sec? 2 ø
- Message? FROM OUR DELI ø
- Message number? 3 ø
- Display in sec? .5 ø
- Message? (space) ø
- Message number? ø
- A*
- Note that message 3 is a blank displayed for half a second.
- PRINT MESSAGES (P ME)
- A* PRINT MESSAGE ø
- N. Sec Message
- 1 2.00 TRY A HOT SANDWICH
- 2 2.00 FROM OUR DELI
- 3 0.50
- A*
- REMOVE MESSAGES (REM ME)
- A* REMOVE MESSAGE;C ø
- Message number? 1 ø
- Message number? 5 ø
- Message number? ø
- A*
- 5 Productos combustibles
- Cómo añadir o cambiar productos combustibles
- Cómo inicializar la información de los productos combustibles
- REMOVE PRODUCT;A (REM PRO;A)
- A* REMOVE PRODUCT;A ø
- A*
- LOAD PRODUCT;A (LO PRO;A)
- A* LOAD PRODUCT;A ø
- Product code? 1 ø
- Category? 1 ø
- Product name? REGULAR ø
- Minimum price? 0 ø
- Maximum price? 0 ø
- Taxes? 0 ø
- Product code? 2 ø
- Category? 1 ø
- Product name? PREMIUM ø
- Minimum price? 0 ø
- Maximum price? 0 ø
- Taxes? 0 ø
- Product code? ø
- A*
- LOAD PRODUCT (LO PRO)
- A* LOAD PRODUCT ø
- Product code? 1 ø
- Category? 1 ø
- Product name? DIESEL ø
- Minimum price? 0 ø
- Maximum price? 0 ø
- Taxes? 0 ø
- A*
- PRINT PRODUCT (P PRO)
- A* PRINT PRODUCT;I 1 ø
- Pr Cat Product Inventory Reorder Low price High price Price Taxes
- 1 1 Regular 0 0 -No Override- 0.00 None
- 2 1 Unleaded 0 0 -No Override- 0.00 None
- 3 1 Premium 0 0 -No Override- 0.00 None
- 4 1 Diesel 0 0 -No Override- 0.00 None
- A*
- REMOVE PRODUCT (REM PRO)
- A* REMOVE PRODUCT ø
- Product code? 1 ø
- A*
- LOAD INVENTORY (LO IN)
- A* LOAD INVENTORY;C ø
- Product? 1 ø
- Quantity? 4300 ø
- Reorder level? 1000 ø
- Product? 3 ø
- Quantity? 2900 ø
- Reorder level? 800 ø
- Product? ø
- A*
- 6 Comandos del tanque y la bomba
- Comandos del tanque
- PRINT TANK (P TA)
- A* PRINT TANK ø
- T# Product Total Reorder Gauge Diff % Temp Ullage
- 1 Regular 5000.000 5000.000 4995 5 0.1 65.2 5005
- 2 Unleaded 6240.000 5000.000 6240 0 0.0 65.2 3760
- 3 Diesel 19840.000 8000.000 19844 4 0.1 65.2 156
- 4 Premium 10000.000 5000.000 9999 1 0.1 65.2 1
- A*
- ADD TANK (AD TA)
- A* ADD TANK ø
- Tank number? 14 ø
- Quantity? 5000 ø
- A*
- SUBTRACT TANK (SUB TA)
- A* SUBTRACT TANK ø
- Tank number? 2 ø
- Quantity? 100 ø
- A*
- LOAD TANK (LO TA)
- A* LOAD TANK ø
- Tank number? 1 ø
- Quantity? 30000 ø
- Product code? 1 ø
- Reorder level? 5000 ø
- A*
- PRINT PRICE (P PR)
- A* PRINT PRICE ø
- Pc Pl Price
- 1 0 1.169 1 1.169 2 1.199
- 2 0 1.229 1 1.229 2 1.299
- 3 0 1.299 1 1.299 2 1.306
- A*
- ________________
- Price codes are rows and price levels are columns. Thus, in the above example, the price charged ...
- A* PRINT PRICE 1 ø
- Pc Pl Price
- 1 0 1.169 1 1.169 2 1.199
- A*
- LOAD PRICE (LO PR)
- A* LOAD PRICE ø
- Price code? 2 ø
- Price level? 1 ø
- Price? 1.119 ø
- Price level? ø
- A*
- A* LOAD PRICE;C ø
- Price code? 1 ø
- Price level? 0 ø
- Price? 1.149 ø
- Price level? 1 ø
- Price? 1.169 ø
- Price level? 2 ø
- Price? 1.199 ø
- Price level? ø
- Price code? ø
- A*
- A* LOAD PRICE * * +.05 ø
- A*
- REMOVE PRICE (REM PR)
- A* REMOVE PRICE ø
- Price code? 4 ø
- Price level? 3 ø
- Price level? ø
- A*
- A* TYPE PRC1.CMD ø
- stop
- lo pri;c
- 1 0 .799 1 .759 2 .799
- 2 0 .859 1 .819 2 .859
- 3 0 .919 1 .879 2 .919
- 4 0 1.069 1 1.029 2 1.069
- run
- A* TYPE PRC2.CMD ø
- stop
- lo pri;c
- 1 0 1.279 1 1.239 2 1.279
- 2 0 1.339 1 1.299 2 1.339
- 3 0 1.459 1 1.419 2 1.459
- 4 0 1.179 1 1.139 2 1.179
- run
- A*
- LOAD FUEL (LO FU)
- A* LOAD FUEL ø
- Pump number? 13 ø
- Hose number? 1 ø
- Product code? 1 ø
- Price code? 1 ø
- Tank number? 1 ø
- Hose number? 2 ø
- Product code? 2 ø
- Price code? 2 ø
- Tank number? 2 ø
- Hose number? ø
- A*
- A* LOAD FUEL ø
- Pump number? * ø
- Hose number? 1 ø
- Product code? 1 ø
- Price code? 1 ø
- Tank number? 1 ø
- Hose number? 2 ø
- Product code? 2 ø
- Price code? 2 ø
- Tank number? 2 ø
- Hose number? ø
- A*
- PRINT PUMP (P PU)
- A* PRINT PUMP ø
- P# T# Pr Pc Price Totals $Total Rate Limit Slow
- 1 1 1 1 0.799 178.770 181.10 100/$ $30 0.500
- 2 2 2 0.859 360.716 322.74 Pumping
- 3 3 3 0.919 740.360 741.94
- 2 1 1 1 0.799 84.110 66.44 100/$ $30 0.500 Down
- 2 2 2 0.859 2.140 1.83
- 3 3 3 0.919 462.540 494.42
- 3 3 3 3 0.919 353.044 357.14 100/$ $30 0.500
- 4 4 4 4 1.069 336.634 349.97 100/$ $30 0.500 Pumping
- 5 1 1 1 0.799 7019.954 6722.35 100/G $500 0.500
- 6 2 2 2 0.859 503.411 548.22 100/G $30 0.500 Pumping
- 7 3 3 3 0.919 464.840 578.71 100/G $30 0.500
- 8 4 4 4 1.069 778.470 804.44 100/G $30 0.500
- ========= =========
- 11284.99 11169.30
- A*
- A* PRINT PUMP;A ø
- P# T# Pr Pc Price Totals $Total Q Previous $ Previous
- 1 1 1 1 0.799 178.770 181.10 29.700 23.73
- 2 2 2 0.859 360.716 322.74 22.600 19.41
- 3 3 3 0.919 740.360 741.94 45.500 41.81
- 2 1 1 1 0.799 84.110 66.44 0.000 0.00
- 2 2 2 0.859 2.140 1.83 0.000 0.00
- 3 3 3 0.919 462.540 494.42 10.000 9.19
- 3 3 3 3 0.919 353.044 357.14 20.000 18.38
- 4 4 4 4 1.069 336.634 349.97 0.000 0.00
- 5 1 1 1 0.799 7019.954 6722.35 55.900 44.66
- 6 2 2 2 0.859 503.411 548.22 33.700 28.95
- 7 3 3 3 0.919 464.840 578.71 15.500 14.24
- 8 4 4 4 1.069 778.470 804.44 44.000 47.03
- ======== ========
- 11284.99 11169.30
- A*
- LOAD PUMP (LO PU)
- A* LOAD PUMP ø
- Pump number? 1 ø
- Hose number? 1 ø
- Quantity? 5624.8 ø
- $ amount? 3217.95 ø
- Hose number? ø
- A*
- RESET PUMP (RE PU)
- A* RESET PUMP ø
- Verify (y/n)? y ø
- A*
- LOAD CUTOFF (LO CU)
- A* LOAD CUTOFF ø
- Pump number? 1 ø
- Fill limit? $50 ø
- Slow cutoff? .25 ø
- A*
- A* LOAD CUTOFF ø
- Pump number? * ø
- Fill limit? $40 ø
- Slow cutoff? .10 ø
- A*
- 7 Productos
- Cómo añadir o cambiar productos
- Cómo crear un nuevo producto
- LOAD PRODUCT;A (LO PRO;A)
- A* LOAD PRODUCT;AC ø
- Product code? 10 ø
- Category? 2 ø
- Product name? MILK ø
- Minimum price? .45 ø
- Maximum price? 3.00 ø
- Taxes? 0 ø
- Product code? 11 ø
- Category? 3 ø
- Product name? SODA ø
- Minimum price? .30 ø
- Maximum price? 2.00 ø
- Taxes? 1 ø
- Product code? ø
- A*
- ENABLE PRODUCT (E PRO)
- A* LOAD PRODUCT;A ø
- Product code? 20 ø
- Category? 9 ø
- Product name? Refund ø
- Minimum price? .01 ø
- Maximum price? 150.00 ø
- Taxes? 0 ø
- A* ENABLE PRODUCT ø
- Product code? 20 ø
- Type ? 1 ø
- A* LOAD PRODUCT;A ø
- Product code? 21 ø
- Category? 9 ø
- Product name? Withdr ø
- Minimum price? .01 ø
- Maximum price? 150.00 ø
- Taxes? 0 ø
- A* ENABLE PRODUCT ø
- Product code? 21 ø
- Type ? 3 ø
- A*
- A* PRINT PRODUCT;AI 37ø
- Pr Cat Name Enabled
- 24 37 Chips 5
- 25 37 Candy 5
- 26 37 Snakes 5
- A*
- LOAD PRODUCT (LO PRO)
- A* LOAD PRODUCT ø
- Product code? 10 ø
- Category? 2 ø
- Product name? DELI ø
- Minimum price? .5 ø
- Maximum price? 5.00 ø
- Taxes? 1 ø
- A*
- PRINT PRODUCT (P PRO)
- A* PRINT PRODUCT ø
- Pr Cat Product Inventory Reorder Low price High price Price Taxes
- 1 1 Regular 0 0 -No Override- 0.00 None
- 2 1 Unleaded 0 0 -No Override- 0.00 None
- 3 1 Premium 0 0 -No Override- 0.00 None
- 4 1 Diesel 0 0 -No Override- 0.00 None
- Pr Cat Product Inventory Reorder Low price High price Price Taxes
- 5 2 Cigs $321.05 100 0.75 1.50 1.20 5
- 6 2 Tires $400.00 150 35.00 125.00 Code 7 8
- 7 2 Bread $21.12 10 0.69 1.10 0.98 None
- 8 2 Soda $250.25 110 0.25 0.75 0.45 2
- A*
- A* PRINT PRODUCT 5-8 ø
- Pr Cat Product Inventory Reorder Low price High price Price Taxes
- 5 2 Cigs $321.05 100 0.75 1.50 1.20 5
- 6 2 Tires $400.00 150 35.00 125.00 Code 7 8
- 7 2 Bread $21.12 10 0.69 1.10 0.98 None
- 8 2 Soda $250.25 110 0.25 0.75 0.45 2
- A*
- A* PRINT PRODUCT;I 2 ø
- Pr Cat Product Inventory Reorder Low price High price Price Taxes
- 5 2 Oil 321 100 0.75 1.50 1.20 5
- 6 2 Tires 400 150 35.00 125.00 Code 7 8
- 7 2 Bread 20 10 0.69 1.10 0.98 None
- 8 2 Soda 250 110 0.25 0.75 0.45 2
- A*
- REMOVE PRODUCT (REM PRO)
- A* REMOVE PRODUCT ø
- Product code? 10 ø
- A*
- LOAD PLU (LO PLU)
- A* LOAD PLU;C ø
- Product? 11 ø
- Price? $1.05 ø
- Product? 12 ø
- Price? $0.98 ø
- Product? 13 ø
- Price? $4 ø
- Product ø
- A*
- LOAD INVENTORY (LO IN)
- A* LOAD INVENTORY ø
- Product? 1 ø
- Quantity? 400 ø
- Reorder level? 100 ø
- A*
- ADD INVENTORY (AD IN)
- A* ADD INVENTORY ø
- Product? 2 ø
- Quantity? 500 ø
- Product? 3 ø
- Quantity? 230 ø
- Product? ø
- A*
- SUBTRACT INVENTORY (SU IN)
- A* SUBTRACT INVENTORY;C ø
- Product? 2 ø
- Quantity? 300 ø
- Product? 4 ø
- Quantity? 65 ø
- Product? ø
- A*
- ENABLE PRODUCT (E PRO)
- A* ENABLE PRODUCT ø
- Product Code? 11 ø
- Type? 4 ø
- A*
- DISABLE PRODUCT (DI PRO)
- A* DISABLE PRODUCT ø
- Product Code? 10 ø
- Type? 5 ø
- A*
- 8 Configuration de las tablas impositivas
- Los tres tipos de impuesto
- Acumuladores de impuestos
- LOAD TAX (LO TAX)
- A* LOAD TAX ø
- Tax #? 3 ø
- Name? Alc.Tx ø
- A*
- PRINT SALES;I 0 (P SA;I 0)
- A* PRINT SALES;I 0 ø
- - Shift 1 from Thu ll/05/92 8:00 AM to Thu 11/05/92 4:00 PM -
- Pr Cat Name Club Debit Credit Cash Total
- T1 0 Sale Tx 0.00 0.00 51.31 49.39 100.70
- T2 0 Tob. Tx 0.00 0.00 22.97 31.18 54.15
- T3 0 Alc. Tx 0.00 0.00 13.33 16.88 30.21
- ==== ==== ===== ===== ======
- 0.00 0.00 87.61 97.45 185.06
- - Totals from Sun ll/01/92 8:00 AM to Thu 11/05/92 4:00 PM -
- Pr Cat Name Club Debit Credit Cash Total
- T1 0 Sale Tx 26.00 10.50 251.31 489.39 777.20
- T2 0 Tob. Tx 10.88 3.55 112.97 231.18 358.58
- T3 0 Alc. Tx 4.20 2.77 113.33 116.84 237.14
- ===== ===== ====== ====== =======
- 41.08 16.82 477.61 837.41 1372.92
- A*
- Cómo restablecer los totales de impuestos acumulativos
- Impuesto porcentual
- Cuándo usar tablas impositivas
- Cómo configurar una tabla impositiva
- 1. Preparación de una descripción comprimida de los datos tributarios.
- 2. Asignación de espacio de almacenamiento para la información tributaria.
- 3. Asignación de un número de impuesto y un nombre a la tabla.
- 4. Elaboración de la tabla impositiva con el programa TAX.
- 5. Hacer una copia de seguridad de los datos de la tabla.
- 1. Preparación de una descripción comprimida de los datos tributarios
- Amt Tax Amt Tax
- From To Tax diff diff From To Tax Diff Diff
- 0.00 0.09 0.00 - - 8.10 8.27 0.45 0.19 0.01
- 0.10 0.27 0.01 - - 8.28 8.45 0.46 0.18 0.01
- 0.28 0.45 0.02 0.18 0.01 8.46 8.63 0.47 0.18 0.01
- 0.46 0.63 0.03 0.18 0.01 8.64 8.81 0.48 0.18 0.01
- 0.64 0.81 0.04 0.18 0.01 8.82 8.99 0.49 0.18 0.01
- 0.82 0.99 0.05 0.18 0.01 9.00 9.18 0.50 0.18 0.01
- 1.00 1.18 0.06 0.18 0.01 9.19 9.36 0.51 0.19 0.01
- 1.19 1.36 0.07 0.19 0.01 9.37 9.54 0.52 0.18 0.01
- 1.37 1.54 0.08 0.18 0.01 9.55 9.72 0.53 0.18 0.01
- 1.55 1.72 0.09 0.18 0.01 9.73 9.90 0.54 0.18 0.01
- 1.73 1.90 0.10 0.18 0.01 9.91 10.09 0.55 0.18 0.01
- 1.91 2.09 0.11 0.18 0.01 10.10 10.27 0.56 0.19 0.01
- 2.10 2.27 0.12 0.19 0.01 10.28 10.45 0.57 0.18 0.01
- 2.28 2.45 0.13 0.18 0.01 10.46 10.63 0.58 0.18 0.01
- 2.46 2.63 0.14 0.18 0.01 10.64 10.81 0.59 0.18 0.01
- 2.64 2.81 0.15 0.18 0.01 10.82 10.99 0.60 0.18 0.01
- 2.82 2.99 0.16 0.18 0.01 11.00 11.18 0.61 0.18 0.01
- 3.00 3.18 0.17 0.18 0.01 11.19 11.36 0.62 0.19 0.01
- 3.19 3.36 0.18 0.19 0.01 11.37 11.54 0.63 0.18 0.01
- 3.37 3.54 0.19 0.18 0.01 11.55 11.72 0.64 0.18 0.01
- 3.55 3.72 0.20 0.18 0.01 11.73 11.90 0.65 0.18 0.01
- 3.73 3.90 0.21 0.18 0.01 11.91 12.09 0.66 0.18 0.01
- 3.91 4.09 0.22 0.18 0.01 12.10 12.27 0.67 0.19 0.01
- 4.10 4.27 0.23 0.18 0.01 12.28 12.45 0.68 0.18 0.01
- 4.28 4.45 0.24 0.19 0.01 12.46 12.63 0.69 0.18 0.01
- 4.46 4.63 0.25 0.18 0.01 12.64 12.81 0.71 0.18 0.01
- 4.64 4.81 0.27 0.18 0.01 12.82 12.99 0.72 0.18 0.01
- 4.82 4.99 0.27 0.18 0.01 13.00 13.18 0.72 0.18 0.01
- 5.00 5.18 0.28 0.18 0.01 13.19 13.36 0.73 0.19 0.01
- 5.19 5.36 0.29 0.19 0.01 13.37 13.54 0.74 0.18 0.01
- 5.37 5.54 0.30 0.18 0.01 13.55 13.72 0.75 0.18 0.01
- 5.55 5.72 0.31 0.18 0.01 13.73 13.90 0.76 0.18 0.01
- 5.73 5.90 0.32 0.18 0.01 13.91 14.09 0.77 0.18 0.01
- 5.91 6.09 0.33 0.18 0.01 14.10 14.27 0.78 0.19 0.01
- 6.10 6.27 0.34 0.19 0.01 14.28 14.45 0.79 0.18 0.01
- 6.28 6.45 0.35 0.18 0.01 14.46 14.63 0.80 0.18 0.01
- 6.46 6.63 0.36 0.18 0.01 14.64 14.81 0.81 0.18 0.01
- 6.64 6.81 0.37 0.18 0.01 14.82 14.99 0.82 0.18 0.01
- 6.82 6.99 0.38 0.18 0.01 15.00 15.18 0.83 0.18 0.01
- 7.00 7.18 0.39 0.18 0.01 15.19 15.36 0.84 0.19 0.01
- 7.19 7.36 0.40 0.19 0.01 15.37 15.54 0.85 0.18 0.01
- 7.37 7.54 0.41 0.18 0.01 15.55 15.72 0.86 0.18 0.01
- 7.55 7.72 0.42 0.18 0.01 15.73 15.90 0.87 0.18 0.01
- 7.73 7.90 0.43 0.18 0.01 15.91 16.09 0.88 0.18 0.01
- 7.91 8.09 0.44 0.18 0.01 16.10 16.27 0.89 0.19 0.01
- 4. Complete la hoja de trabajo indicando las diferencias en cantidades y las diferencias impositi...
- 5. Examine la columna Amt Diff en la hoja de trabajo. Observe que hay un patrón regular. Cinco in...
- 6. Encuentre un patrón de repetición en los incrementos de la columna Tax Diff (puede ser que sea...
- 7. Luego encuentre un patrón de repetición que represente los incrementos en ambas columnas Diff....
- 2. Asignación de espacio de almacenamiento para la información tributaria
- 3. Asignación de un número de impuesto y un nombre a cada tabla
- 4. Elaboración de una tabla impositiva
- TAX
- C* TAX ø
- TAX program.
- Enter ? for help.
- Table status: size = 20 records, used = 8, available = 12
- Tax number, P, P#, T, T#, or Q to quit? 1 ø
- Tax type, Q to quit, RETURN for same? 1 ø
- New calculation number entered.
- Initializing new tax calculation table.
- Smallest taxable amount (cents)? 10 ø
- Enter command (I, L, E, Q, D, P, M, or S)? L ø
- Loop how many times (0 = until done)? 8 ø
- Enter command (I, L, E, Q, D, P, M, or S)? i ø
- Increment how many times (0 = until done)? 5 ø
- Taxable amount increment (cents)? 18 ø
- All tax increments one cent (Y/N)? y ø
- Enter command (I, L, E, Q, D, P, M, or S)? i ø
- Increment how many times (0 = until done)? 1 ø
- Taxable amount increment (cents)? 19 ø
- Enter command (I, L, E, Q, D, P, M, or S)? i ø
- Increment how many times (0 = until done)? 4 ø
- Taxable amount increment (cents)? 18 ø
- Enter command (I, L, E, Q, D, P, M, or S)? i ø
- Increment how many times (0 = until done)? 1 ø
- Taxable amount increment (cents)? 19 ø
- Enter command (I, L, E, Q, D, P, M, or S)? e ø
- End loop
- Enter command (I, L, E, Q, D, P, M, or S)? p ø
- Tax number 1: SALES T
- Type 1: table lookup
- Loop Rec Record Apply Amount Tax
- Level Nbr Type Times Increment Increment
- ---- --- ----- ----- --------- ---------
- 1 Initial - $0.10 --
- + 2 Loop 8 --- --
- | 3 Increment 5 $0.18 $0.01
- | 4 Increment 1 $0.19 $0.01
- | 5 Increment 4 $0.18 $0.01
- | 6 Increment 1 $0.19 $0.01
- + 7 End loop - ----- -----
- Enter command (I, L, E, Q, D, P, M, or S)? q ø
- End table
- Table status: size = 20 records, used = 17, available = 3
- Save the updated tax table (Y, N, or P)? y ø
- Tax table saved
- Table status: size = 20 records, used = 17, available = 3
- Tax number, P, P#, T, T#, or Q to quit? q ø
- C*
- 9 Informes, efectivo en caja y, turnos
- 10 Transacciones
- Impresión de transacciones
- PRINT TRANSACTION (P TR)
- A* PRINT TRANSACTION ø
- Tran Card Account Veh Date Time P# Pr Qty Price $Total Error
- 1201 65289 5006127285 9183 2/28 10:58 1 1 4.851 1.159 5.62
- 1202 65180 9097075558 6249 2/28 10:58 4 4 9.794 1.049 10.27
- 1203 82429 3834546687 2491 2/28 10:59 2 2 13.281 1.119 14.86
- 1204 56218 3859872185 1126 2/28 10:59 3 3 8.606 1.299 11.18
- 1205 28593 4136528253 9138 2/28 11:01 2 2 19.195 1.119 21.48
- 1206 82429 3834546687 2491 2/28 11:02 1 1 9.247 1.159 10.72
- . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
- 1234 82429 3834546687 2491 2/28 11:20 4 4 12.449 1.099 13.68
- 1235 65180 9097075558 6249 2/28 11:20 2 2 14.761 1.069 15.78
- 1236 56218 3859872185 1126 2/28 11:22 4 4 35.000 1.099 38.47 LIMIT
- 1237 28593 4136528253 9138 2/28 11:22 3 3 13.635 1.299 17.71
- 1238 82429 3834546687 2491 2/28 11:23 2 2 4.197 1.119 4.70
- 1239 65289 5006127285 9183 2/28 11:23 1 1 6.557 1.159 7.60
- 1240 65180 9097075558 6249 2/28 11:24 2 2 9.316 1.069 9.96
- ======= ======
- 448.281 514.84
- A*
- A* PRINT TRANSACTION;P2=ACCOUNT,P1=PR ø
- Tra Card Account Veh Date Time P# Pr Qty Price $Total Error
- 1206 82429 3834546687 2491 2/28 11:02 4 1 9.247 1.159 10.72
- 1220 82429 3834546687 2491 2/28 11:12 4 1 3.879 1.159 4.50
- ------ -----
- 13.126 15.22
- 1203 82429 3834546687 2491 2/28 10:59 3 2 13.281 1.119 14.86
- 1238 82429 3834546687 2491 2/28 11:23 3 2 4.197 1.119 4.70
- ------ -----
- 17.478 19.56
- 1215 82429 3834546687 2491 2/28 11:08 2 3 6.043 1.299 7.85
- 1224 82429 3834546687 2491 2/28 11:14 2 3 13.090 1.299 17.00
- ----- -----
- 19.133 24.85
- 1229 82429 3834546687 2491 2/28 11:17 1 4 16.604 1.099 18.25
- 1234 82429 3834546687 2491 2/28 11:20 1 4 12.449 1.099 13.68
- ------ -----
- 9.053 31.93
- ====== =====
- 8.790 91.56
- A*
- PRINT TIP (P TI)
- A* PRINT TIP ø
- Seq P# Pr Device Acct Card # Quantity $Total Status
- 340 11 1 POS Cash 5.490 4.77 Pumping
- 339 1 1 Reader Club 25555877413335922 0.000 0.00 Need verf
- 330 12 2 POS Cash 5.330 4.90 Pumping
- A*
- RESET TRANSACTION (RE TR)
- A* RESET TRANSACTION ø
- Trans #? 4
- Verify (y/n)? y ø
- R
- PURGE SITE (PU SIT)
- A* PURGE SITE ø
- Verify (y/n)? y ø
- A*
- 4416 80140 Sft-01 POS-03 Clerk-01 10/02 05:46AM $0.00 tax 0.00 $17.00
- Pump-05 Fuel-90 Credit-04 14.925G @1.139 $17.00 odo- aux-
- Paid: Visa 4602230000112661 Auth# 001285 $17.00 Chg: 0.00
- 4417 80244 Sft-01 ICR-05 Clerk-00 10/02 06:14AM $0.00 tax 0.00 $5.30
- Pump-02 Fuel-90 Credit-04 4.654G @1.139 $5.30 odo- aux-
- Paid: Visa 4680180002848769 Auth# 002261 $5.30 Chg: 0.00
- 4418 80272 Sft-01 POS-03 Clerk-01 10/02 06:19AM $0.88 tax 0.06 $15.95
- Pump-06 Fuel-91 Credit-04 12.067G @1.239 $14.95 odo- aux-
- 2 0.47 34 oz Refill
- Paid: Visa 4680180000381243 Auth# 002747 $15.95 Chg: 0.00
- 4419 80479 Sft-01 POS-03 Clerk-01 10/02 06:55AM $1.40 tax 0.09 $18.58
- Pump-01 Fuel-90 Credit-04 14.924G @1.139 $17.00 odo- aux-
- 1 1.49 Sinclair 10w
- Paid: Visa 4053851521025308 Auth# 050195 $18.58 Chg: 0.00
- 4420 80524 Sft-01 ICR-10 Clerk-00 10/02 07:05AM $0.00 tax 0.00 $17.70
- Pump-07 Fuel-91 Credit-04 14.286G @1.239 $17.70 odo- aux-
- Paid: Visa 4678011029088 Auth# 020150 $17.70 Chg: 0.00
- $Total: $74.53 Fuel: 71.95
- 4416 80140 Sft-01 POS-03 Clerk-01 10/02/95 05:46AM
- 14.925G @1.139 Fuel-90 $ 17.00 Pump-05 Credit-04 odo- aux-
- Total 17.00
- Paid 17.00 Visa 4602230000112661 Auth# 001285
- Change 0.00
- 4417 80244 Sft-01 ICR-05 Clerk-00 10/02/95 06:14AM
- 4.654G @1.139 Fuel-90 $ 5.30 Pump-02 Credit-04 odo- aux-
- Total 5.30
- Paid 5.30 Visa 4680180002848769 Auth# 002261
- Change 0.00
- 4418 80272 Sft-01 POS-03 Clerk-01 10/02/95 06:19AM
- 12.067G @1.239 Fuel-91 $ 14.95 Pump-06 Credit-04 odo- aux-
- 2 0.47 34 oz Refill 0.94 Dept# 15 Item# 00102
- Tax 0.06
- Total 15.95
- Paid 15.95 Visa 4680180000381243 Auth# 002747
- Change 0.00
- 4419 80479 Sft-01 POS-03 Clerk-01 10/02/95 06:55AM
- 14.924G @1.139 Fuel-90 $ 17.00 Pump-01 Credit-04 odo- aux-
- 1 1.49 Sinclair 10w 1.49 Dept# 01 Item# B7422903702
- Tax 0.09
- Total 18.58
- Paid 18.58 Visa 4053851521025308 Auth# 050195
- Change 0.00
- 4420 80524 Sft-01 ICR-10 Clerk-00 10/02/95 07:05AM
- 14.286G @1.239 Fuel-91 $ 17.70 Pump-07 Credit-04 odo- aux-
- Total 17.70
- Paid 17.70 Visa 4678011029088 Auth# 020150
- Change 0.00
- $Total: $74.53 Fuel: 71.95
- 11 Tarjetas personales
- Formato de las tarjetas personales
- Cómo restringir las compras
- Exclusiones
- Exclusión con asignación de bits
- Exclusión limitada
- Opciones de exclusión positiva y negativa
- Exclusión con asignación de bits en disco
- Cómo excluir y desbloquear tarjetas
- Cómo verificar el estado de exclusión de una tarjeta
- Cómo imprimir una lista de exclusiones
- Códigos de autorización
- Códigos de limitación de combustible
- ID de grupo de consumidores de combustible - Paquetes para flotas solamente
- 12 Programa Lookup
- 13 Cuota de combustible y millas por galón
- 14 Copia de sequridad de los datos del sistema
- ¿Por qué hacer copias de seguridad?
- Los archivos de seguridad
- Cómo hacer una copia de seguridad de los datos del sistema
- Cómo hacer copias de seguridad de las transacciones
- Cómo proteger contra escritura a los disquetes que contienen copias de seguridad
- Cómo restaurar datos del sistema o de las transacciones
- Cómo hacer copias de seguridad y restaurar archivos en el disco duro
- Cómo hacer una copia de seguridad de todos los archivos con RCP
- Cómo restaurar archivos cuyas copias de seguridad se hicieron con RCP
- Cómo hacer copias de seguridad de los archivos del sistema con el comando HARDBACK
- Cómo restaurar archivos cuyas copias de seguridad se hicieron con el comando HARDBACK
- 15 Sistema de archivos del SC
- Qué es un archivo del Site Controller II
- El sistema de archivos
- Archivos del Site Controller
- RECORD (REC)
- A* RECORD ø
- File name? PRDATA.CMD ø
- Data? PRINT DATE ø
- Data? PRINT DRAWER ø
- Data? PRINT TANK ø
- Data? ^C ø
- A*
- A* RECORD ø
- File name? DIPSTICK ø
- Data? 2/8/95 TANK 1 5530 ø
- Data? 2/8/95 TANK 2 4230 ø
- Data? ^C ø
- A*
- TYPE (TY)
- A* TYPE PRDATA.CMD ø
- PRINT DATE
- PRINT DRAWER
- PRINT TANK
- A* TYPE DIPSTICK ø
- 2/8/95 TANK 1 5530
- 2/8/95 TANK 2 4230
- A*
- DELETE (DEL)
- A* DELETE PRDATA.CMD ø
- A* *
- COPY (COP)
- A* COPY PRICE.CMD PRICE.BAK ø
- A*
- RENAME (REN)
- A* RENAME PRICE.CMD PRICE.BAK ø
- A* *
- RENAME (REN)
- A* RENAME PRICE.CMD PRICE.BAK ø
- A* *
- DIRECTORY (DIR)
- A* DIRECTORY ø
- File name Size Last modified
- FRAMOS BIN 267900 Thu 11/16/95 12:41 PM
- FRAMOS CFG 12572 Thu 11/16/95 11:12 AM
- BIN <DIR> Thu 11/16/95 12:35 PM
- PROM <DIR> Thu 11/16/95 12:35 PM
- SREC <DIR> Thu 11/16/95 12:35 PM
- 5 File(s) using 280472 bytes, 43008 bytes free
- A*
- A* DIRECTORY D: ø
- File name Size Last modified
- CON01 CMD 836 Tue 11/21/95 2:41 PM
- CON02 CMD 326 Thu 11/23/95 7:32 AM
- CON03 CMD 166 Thu 11/23/95 10:45 AM
- 3 File(s) using 1328 bytes, 10467 free
- A*
- A* DIRECTORY;A /MY_CMDS ø
- File name Size Last modified
- .
- ..
- CON01 CMD 836 Tue 11/21/95 2:41 PM
- CON02 CMD 326 Thu 11/23/95 7:32 AM
- CON03 CMD 166 Thu 11/23/95 10:45 AM
- 5 File(s) using 1328 bytes, 40352 free
- A*
- A* DIRECTORY;I C: ø
- Directory
- FRAMOS.BIN FRAMOS.CFG BIN/ PROM/ LOCAL/
- 5 file(s) using 337578 bytes, 30732288 free
- A*
- TREE
- A* TREE A: ø
- RESTORE.BIN
- BACKTRAN.BIN
- SYSBAC K.CMD
- TRANBACK.CMD
- TREE.BIN
- TRAN_BAK/SEP_30.TRN
- TRAN _BAK/OCT_01.TRN
- TRAN_BAK/OCT_02.TRN
- TRAN_BAK/OCT_O3.TRN
- A*
- MKDIR (MK)
- A* MKDIR MY_CMDS ø
- A*
- CHDIR (CHD)
- A* CHDIR MY_CMDS ø
- A*
- A* CHDIR D: ø
- A*
- WHERE
- A* WHERE ø
- Current directory - A:
- A* CHDIR BIN ø
- A* WHERE ø
- Current directory = A:BIN/
- A*
- RCP
- A* RCP C:/TRAN_BAK A: ø
- SEP_30.TRN
- OCT_01.TRN
- OCT_02.TRN
- OCT_O3.TRN
- A
- RMDIR (RM)
- A* RMDIR MY_CMDS ø
- A*
- FORMAT
- A* FORMAT ø
- Disk (A, B or D)? A ø
- Disk type [4]? 3 ø
- Verify (y/n)? Y ø
- A*
- CHKDSK
- A* CHKDSK A ø
- 730112 bytes total disk space
- 4096 bytes in 3 directories
- 696320 bytes in 58 user files
- 29696 available on disk
- A*
- SWAPCOPY
- A* SWAPCOPY TRANS TRANS.BAK ø
- Insert SOURCE disk then return . . . ø
- Insert DESTINATION disk then return . . . ø
- A*
- A* SWAPCOPY - ø
- This command will make a duplicate of the disk in A:
- The site will be taken down during the operation.
- Proceed? (Y/N) Y ø
- Insert SOURCE disk. Hit any key when ready.... ø
- Insert DESTINATION disk. Hit any key when ready.... ø
- Insert SOURCE disk. Hit any key when ready.... ø
- Insert DESTINATION disk. Hit any key when ready.... ø
- Insert SOURCE disk. Hit any key when ready.... ø
- Insert DESTINATION disk. Hit any key when ready.... ø
- Insert BOOT disk. Hit any key when ready.... ø
- A*
- A* SWAPCOPY + ø
- This command will make a duplicate of the disk in A: to B:
- Proceed? (Y/N) Y ø
- A*
- C* DISKCOPY ø
- This is a utility to copy the disk in drive A
- Put the source in drive A
- Press Y to start copying or N to quit . . . Y ø
- Making temporary directory
- Copying files from A drive . . .
- FILE1.DAT
- FILE2.DAT
- Remove source disk and
- Place blank formatted disk in drive A
- Press Y to start copying or N to quit . . . Y ø
- Copying files to A drive . . .
- FILE1.DAT
- FILE2.DAT
- C*
- 16 Uso del editor de la pantalla
- Los modos del editor
- Uso del editor: aspectos básicos
- Cómo introducir texto
- Cómo corregir el texto a medida que se escribe
- Mayúsculas o minúsculas para escribir los comandos
- El búfer de trabajo
- Cómo asignar nombre a los archivos
- Cómo guardar archivos nuevos
- Cómo volver a guardar archivos
- Cómo salir del editor
- Cómo salir del editor sin guardar
- Cómo mover el cursor
- Cómo insertar texto
- Cómo eliminar el texto
- Cómo iniciar una línea
- Cómo deshacer cambios en una línea
- Cómo unir dos líneas
- Cómo dividir dos líneas
- Cómo copiar una línea
- Cómo reemplazar un carácter
- Edición avanzada
- Cómo mover el cursor a un carácter especificado
- Cómo mover el cursor a una línea especificada
- Cómo buscar una cadena especificada
- Cómo buscar e imprimir una cadena
- Cómo ejecutar una búsqueda y reemplazo global
- Cómo borrar todo el búfer de trabajo
- Cómo borrar líneas especificadas
- Cómo eliminar texto hasta un carácter especificado
- Cómo agregar un archivo al archivo actual
- Cómo establecer tabulaciones
- Cómo editar un archivo nuevo sin salir del editor FRED
- Resumen de comandos del editor
- 17 Cómo crear sus propios comandos
- Restricciones aplicables a los nombres de los archivos de comandos
- Espacio del programa
- Ruta de búsqueda de los comandos
- Cómo ejecutar los archivos de comandos de usuario
- Comentarios en archivos de comandos
- Cómo usar la entrada del terminal con archivos de comandos
- Comandos del archivo de comandos
- Limitaciones de longitud de línea
- Archivos de comandos ejecutados desde una consola
- Archivos de comandos a ser ejecutados en el inicio de sesión
- Cómo guardar la salida desde un archivo de comandos
- Cómo enviar una salida a la impresora de registros
- Cómo enviar una salida a la impresora de recibos
- Cómo añadir un evento al libro diario en disco
- Variables para usar en archivos de comandos
- El comando EXECUTE
- Cómo salir de los archivos de comandos
- 18 Archivos de comandos avanzados
- 19 Comando cron automáticos
- 20 Comunicaciones
- 21 Resumen de los comandos de configuración
- 22 Mantenimiento preventivo
- 23 Comandos de diagnóstico
- Diagnósticos del sistema
- Historial de eventos
- Estado del sistema
- Cómo probar la memoria de una unidad de control de bombas
- Cómo probar una impresora de recibos
- 24 Habilitación e inhabilitación de dispositivos
- Desactivación y reinicio del sistema
- Cómo desactivar un sistema
- Paros de emergencia
- Cómo realizar un paro de emergencia desde el terminal
- Cómo realizar un paro de emergencia desde la consola
- Cómo reiniciar un sistema
- Cómo reiniciar el sistema después de un paro de emergencia de la consola
- Cómo reiniciar el sistema después de una condición grave de sistema inoperativo
- Cómo reinicializar el Site Controller
- Dispositivos del sistema
- Cómo inhabilitar y habilitar una bomba
- Cómo inhabilitar y habilitar una unidad de control de bombas
- Cómo inhabilitar y habilitar un terminal de lector
- Cómo inhabilitar y habilitar una consola
- Cómo inhabilitar y habilitar un sistema de monitoreo de tanques
- Cómo inhabilitar y habilitar un lector de tranquera
- Cómo inhabilitar y habilitar un lector de punto de suministro de combustible
- Cómo inhabilitar y habilitar SDI
- Cómo hacer funcionar manualmente las bombas
- Desactivación y reinicio del sistema
- 25 Paquetes opcionales
- A Interruptores del Site Controller
- B Configuración del terminal de vinculo
- Modo de configuración
- 1. Presione si tiene un sistema Serie 1000 o Sistema A.
- 2. Introduzca el modo de configuración presionando - . (Tenga cuidado de no presionar - . Si lo h...
- General Setup
- Emulation VT52 Auto Page Off
- Enhancements Off Warning Bell On
- Virtual Terminal Off Margin Bell Off
- Scroll Style Jump Bell Sound 1
- Auto Scroll On Block Terminator US/CR
- Auto Wrap On Send ACK Off
- Received CR CR Monitor Mode Off
- Communications Setup
- Main Baud 9600 Aux Baud 9600
- Main Data/Parity 8/None Aux Data/Parity 8/None
- Main Stop Bits 1 Aux Stop Bits 1
- Main Rcv Hndsk XON/XOFF Aux Rev Hndsk NONE
- Main Xmt Hndsk NONE Aux Xmt Hndsk XON/XOFF
- Ignore 8th Bit Off Aux Rev Level 50%
- Comm Mode Full Duplex Aux Port RS232
- Disconnect 2 sec Aux Interface RS232
- Printer Serial
- Display Setup
- Columns 132 Background Dark
- 80/132 Clear On Attributes Char
- Lines 24 Wprt Intensity Dim
- Pages 1X Lines Wprt Reverse Off
- Status Line Ext Wprt Underline Off
- Cursor Style Blink Block Refresh Rate 60Hz
- Cursor On Pound Char US
- Screen Saver 15 Min Auto Font Load On
- Keyboard Setup
- Key Click Off Break 250 ms
- Key Repeat On Xmt Limit None
- Key Lock Caps FKey Xmt Limit None
- Return Key CR Key Code ASCII
- Enter Key CR WP Keyboard Mode Off
- Back Space Key BS/DEL Lock Keyboard Disable
- Left Alt Key Funct Language US
- Delete Key Normal
- ANSI Setup
- FKey Lock Off Print National
- Feature Lock Off Send All
- Keypad Numeric Send Area Screen
- Cursor Keys Normal Print Area Screen
- Xfer Term EOS Send Term None
- Char Mode Multinational Print Term None
- Keys Typewriter Print Mode Auto/Normal
- VT100 ID VT 100 Auto Answerback Off
- Configuración de la impresora Okidata 184
- 1. Coloque la impresora fuera de línea presionando La luz SELECT debe apagarse.
- 2. Coloque el cabezal impresor en la parte superior del papel y presione el botón .
- 3. Vuelva a colocar la impresora en línea presionando La luz SELECT debe encenderse.
- 4. Presione el botón hasta que se encienda la luz que está junto a HSD.
- 5. Presione el botón hasta que se encienda la luz que está junto a 17. (Si los informes de las tr...
- Modo de configuración
- C Selecciones de módem y cables
- D Mensajes de estado y de error
- Mensajes en la impresora de registros
- name table reconstructed
- linename DSR not present
- linename DSR regained
- linename CTS not present
- linename CTS regained
- [Pump #] Card #123124213453 denial_reason WED 11/29/95 12:34 PM
- Bank verification came up
- Battery #X FAILED
- Battery #X OK
- Card Reader Terminal #X came up
- Card Reader Terminal #X disabled
- Card Reader Terminal #X paper low
- Card Reader Terminal #X out of paper
- Card Reader Terminal #X paper ok
- Card Reader Terminal #X printer down
- Card Reader Terminal #X printer jammed
- Card Reader Terminal #X printer unjammed
- Card Reader Terminal #X reader jammed
- Card Reader Terminal #X reader unjammed
- Card reader terminal #X went down
- CFN verification came up
- CFN verification did not respond
- CFN verification went down
- Console #X came up
- Console #X disabled
- Console #X went down
- Data corrupted in table
- DES not ready
- Diagnostics table too small
- Disk error during operation <error> Drive W Cyl X Head Y, Sec Z
- Disk full
- EMERGENCY STOP
- End EMERGENCY STOP
- Fuel Point Reader # on loop # went down
- Fuel Point Reader # came up
- Invalid disk in drive
- Island EMERGENCY STOP
- Loop table overflow
- Master key loaded
- Memory available
- Memory full
- No master key
- No Tokheim handler
- No Wayne handler
- No working key
- Product #XX name below reorder level
- Pump #X disabled
- Pump #X disabled, no quantity
- Pump #X disabled, no price
- Pump #X enabled
- Pump control unit #X came up
- Pump control unit #X disabled
- Pump control unit #X down, bad memory
- Pump control unit #X found unassigned transaction
- Pump control unit #X went down
- RAM battery low
- Remote command: command
- Remote verification did not respond
- SC II Vx (HHMM/MMDDYY) Router:r_name, Handler:h_name Day MM/DD/ YY HH:MM AM/PM
- Site XXXX came up
- Site XXXX went down
- Tank #X below reorder level.
- Tank #X fuel leak
- Tank #X probe error
- Tank #X excess water
- Tank #X YYY Gal Delivery
- Warm boot
- Mensajes que aparecen en el informe impreso de transacciones
- Mensajes en el modo de comando
- BAD MESS
- Can’t activate
- Bad data input
- Can’t open file
- Cannot run program
- Card is not valid
- Card is valid
- Command failed
- Device out of service
- Does not exist
- Error loading program
- File full
- Invalid option
- Manager key required
- No more file space
- Permission denied
- Program checksum error
- Pump deactivated
- Pump is not on
- Pump is ready
- Site is stopped
- Some valid, some not
- String too long
- Transactions in progress
- Unknown command
- Mensajes en la impresora de registros
- E Archivos en los disquetes
- F Comunicaciones mediante conexión telefónica externa
- Tipos de tarjetas
- Numeración de las tarjetas de crédito
- Manejo de transacciones
- Redes de tarjetas que han otorgado certificación al sistema CFN
- Módems
- Glosario
- Indice
