5
Installation clearances:
The location must be large enough to allow the dryer door to
open fully.
Most installations require a minimum 5½" (140 mm) clearance
behind the dryer for the exhaust vent with elbow. See “Venting
Requirements.”
Dryer Dimensions
Most installations require a minimum 5½" (140 mm) clearance
behind the dryer for the exhaust vent with elbow. See “Venting
Requirements.”
■
For closet installation, with a door, minimum ventilation
openings in the top and bottom of the door are required.
Louvered doors with equivalent ventilation openings
are acceptable.
■
Companion appliance spacing should also be considered.
Minimum Required Spacing
Recessed Area Installation
Closet Installation
Back View
Side View
29
1
/
4
"
(
743 mm
)
35"
(889 mm)
8
1
/
4
"
(
210 mm
)
1"
(
25 mm
)
26"
(660 mm)
3
1
/
4
"
(
83 mm
)
7
1
/
2
"
(
191 mm
)
1
1
/
2
"
(
38 mm
)
5
1
/
2
"
(
140 mm
)
10
3
/
4
"
(
273 mm
)
37
1
/
2
"
(953
mm
)
(gas models)
41"
(1042
mm
)
13
1
/
2
"
(
343 mm
)
Electric
Gas
27"
(686
mm
)
3
1
/
4
"
(
83 mm
)
36"
(914
mm
)
(electric models)
4" dia
(
102 mm
)
13
1
/
2
"
(
343 mm
)
0"
(0 mm)
0"
(0 mm)
15"
(381 mm)
14" maximum
(356 mm)
0"
(0 mm)
0"
(0 mm)
14" maximum
(356 mm)
0"
(0 mm)
1"
(25 mm)
3"
(76 mm)
3"
(76 mm)
48 in
2
(310 cm
2
)
24 in
2
(155 cm
2
)
15"
(381 mm)
Minimum spacing for recessed area or closet
installation
The dimensions shown following are for the minimum spacing
allowed.
■
Additional spacing should be considered for ease of
installation and servicing.
■
Additional clearances might be required for wall, door,
and floor moldings.
■
Additional spacing of 1" (25 mm) on all sides of the dryer
is recommended to reduce noise transfer.
Additional spacing recommended
Mobile home – Additional installation requirements
This dryer is suitable for mobile home installations. The
installation must conform to the Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part 3280
(formerly the Federal Standard for Mobile Home Construction
and Safety, Title 24, HUD Part 280) or the Canadian
Manufactured Home Standard CAN/CSA-Z240 MH.
■
Metal exhaust system hardware, which is available
for purchase. For further information, please reference the
“Assistance or Service” section of the Use and Care Guide.
Use and Care Guide is available online at
www.maytag.com
.
■
Special provisions must be made in mobile homes to
introduce outside air into the dryer. The opening (such
as a nearby window) should be at least twice as large
as the dryer exhaust opening.
