13
1.
Place towel on dryer
Place towel on top of dryer to avoid damaging the surface.
Lift door until top screws in dryer cabinet are in large part of
hinge slot. Pull door forward off screws. Set door (handle side
up) on top of dryer. Remove top screws from dryer cabinet.
3.
Lift door off top screws
2.
Remove bottom screws
Open dryer door. Remove bottom screws from dryer cabinet
side of hinges. Loosen (do not remove) top screws from dryer
cabinet side of hinges.
REVERSE DOOR SWING
(OPTIONAL)
NOTE: Magnetized screwdriver is helpful.
27" Wide Model Side-Swing Door
6.
Rotate outer door
Rotate outer door 180º and set it back down on inner door.
Be certain to keep cardboard spacer centered between
doors. Reattach outer door panel to inner door panel so
handle is on the side where hinges were just removed.
Insert six door screws.
Remove screws at top, bottom, and side of door (six screws).
Keep door screws separate from hinge screws as they are
different sizes. Holding door over towel on dryer, grasp sides
of outer door and lift to separate it from inner door.
NOTE: Do not pry apart with putty knife or screwdriver.
Do not pull on door seal or plastic door catches.
5.
Remove screws from door
Remove screws attaching hinges to door.
4.
Remove screws from hinges
