Maytag 27 Inch Electric Dryer Installation Guide - Manual (Página 14)

14
9.
Remove and transfer plugs
Remove the four screws that attach two plugs on the left side.
Transfer plugs to opposite side using the same four screws.
8.
Attach door hinges
Reattach door hinges to dryer door so that the larger hole
is at the bottom of the hinge.
7.
Flip door over
Flip door over so handle side is down.
11.
Check door strike alignment
Close door and check that door strike aligns with door catch.
If it is needed, slide door catch left or right within slot to adjust
alignment.
10.
Insert screws in hinge holes
on dryer cabinet
NOTE: Two people may be needed to reinstall door.
Insert screws into the bottom holes on left side of dryer cabinet.
Tighten screws halfway. Position door so large end of door
hinge slot is over screws. Slide door up so screws are in bottom
of slots. Tighten screws. Insert and tighten top screws in hinges.
DRYER CARE
Cleaning the dryer location
Keep dryer area clear and free from items that would block
the airflow for proper dryer operation. This includes clearing
piles of laundry in front of the dryer.
