Dimensiones en pulgadas (mm)/masa en libras (kg)
Clase de
voltaje
Capacidad
HP (kW)
W
H
D
W1
H1
H2
d
Masa
Fig.
Trifásico
de 200V
0.13 (0.1)
2.68 (68)
5.04 (128)
2.76 (70)
2.20 (56)
4.65 (118)
0.20 (5)
M 4
1.32 (0.6)
1
0.25 (0.2)
2.68 (68)
5.04 (128)
2.76 (70)
2.20 (56)
4.65 (118)
0.20 (5)
M 4
1.32 (0.6)
1
0.5 (0.4)
2.68 (68)
5.04 (128)
4.02(102)
2.20 (56)
4.65 (118)
0.20 (5)
M 4
1.98 (0.9)
1
1 (0.75)
2.68 (68)
5.04 (128)
4.80(122)
2.20 (56)
4.65 (118)
0.20 (5)
M 4
2.43 (1.1)
1
2 (1.5)
4.25 (108)
5.04 (128)
5.08 (129)
3.78 (96)
4.65 (118)
0.20 (5)
M 4
3.09 (1.4)
2
3 (2.2)
4.25 (108)
5.04 (128)
6.06 (154)
3.78 (96)
4.65 (118)
0.20 (5)
M 4
3.31 (1.5)
2
5 (3.7)
5.51 (140)
5.04 (128)
6.34 (161)
5.04(128)
4.65 (118)
0.20 (5)
M 4
4.63 (2.1)
2
Monofás
ico de
200V
0.13 (0.1)
2.68 (68)
5.04 (128)
2.76 (70)
2.20 (56)
4.65 (118)
0.20 (5)
M 4
1.32 (0.6)
1
0.25 (0.2)
2.68 (68)
5.04 (128)
2.76 (70)
2.20 (56)
4.65 (118)
0.20 (5)
M 4
1.54 (0.7)
1
0.5 (0.4)
2.68 (68)
5.04 (128)
4.41 (112)
2.20 (56)
4.65 (118)
0.20 (5)
M 4
2.20 (1.0)
1
1 (0.75)
4.25 (108)
5.04 (128)
5.08 (129)
3.78 (96)
4.65 (118)
0.20 (5)
M 4
3.31 (1.5)
2
2 (1.5)
4.25 (108)
5.04 (128)
6.06 (154)
3.78 (96)
4.65 (118)
0.20 (5)
M 4
3.31 (1.5)
2
Trifásico
de 400V
0.25 (0.2)
4.25 (108)
5.04 (128)
3.19 (81)
3.78 (96)
4.65 (118)
0.20 (5)
M 4
2.20 (1.0)
2
0.5 (0.4)
4.25 (108)
5.04 (128)
3.90 (99)
3.78 (96)
4.65 (118)
0.20 (5)
M 4
2.43 (1.1)
2
1 (0.75)
4.25 (108)
5.04 (128)
5.08 (129)
3.78 (96)
4.65 (118)
0.20 (5)
M 4
3.31 (1.5)
2
2 (1.5)
4.25 (108)
5.04 (128)
6.06 (154)
3.78 (96)
4.65 (118)
0.20 (5)
M 4
3.31 (1.5)
2
3 (2.2)
4.25 (108)
5.04 (128)
6.06 (154)
3.78 (96)
4.65 (118)
0.20 (5)
M 4
3.31 (1.5)
2
5 (3.7)
5.51 (140)
5.04 (128)
6.34 (161)
5.04(128)
4.65 (118)
0.20 (5)
M 4
4.63 (2.1)
2
