5 Instalación eléctrica
YASKAWA Variador de CA TOSP YAIL1E 02A YASKAWA - Precauciones de seguridad L1000E 23
Clase 400 V trifásico
Tabla 6. Calibre de hilo y especificaciones de torque (Trifásico Clase 400 V)
Modelo de
variador
Terminal
Calibre
recomendado
AWG, kcmil
Rango de hilo
AWG, kcmil
Tamaño de
los
tornillos
Torque de apriete
N•m (lb.pulg.)
4A0009
R/L1, S/L2, T/L3
2.5
(14)
2.5 a 6.0
(14 a 10)
M4
1.2 a 1.5
(10.6 a 13.3)
U/T1, V/T2, W/T3
2.5
(14)
2.5 a 6.0
(14 a 10)
–, +1, +2 –
2.5 a 6.0
(14 a 10)
B1, B2 –
2.5 a 6.0
(14 a 10)
6.0
(10)
2.5 a 6.0
(14 a 10)
4A0012
R/L1, S/L2, T/L3
4.0
(12)
2.5 a 6.0
(14 a 10)
M4
1.2 a 1.5
(10.6 a 13.3)
U/T1, V/T2, W/T3
2.5
(14)
2.5 a 6.0
(14 a 10)
–, +1, +2 –
2.5 a 6.0
(14 a 10)
B1, B2 –
2.5 a 6.0
(14 a 10)
6.0
(10)
2.5 a 6.0
(14 a 10)
4A0019
R/L1, S/L2, T/L3
6.0
(10)
2.5 a 16
(12 a 6)
M4
1.2 a 1.5
(10.6 a 13.3)
U/T1, V/T2, W/T3
6.0
(10)
2.5 a 16
(12 a 6)
–, +1, +2 –
4.0 a 16
(12 a 6)
B1, B2 –
4.0 a 6.0
(12 a 10)
6.0
(10)
2.5 a 6.0
(14 a 10)
M5
2 a 2.5
(17.7 a 22.1)
4A0023
R/L1, S/L2, T/L3
6.0
(10)
2.5 a 16
(12 a 6)
M4
1.2 a 1.5
(10.6 a 13.3)
U/T1, V/T2, W/T3
6.0
(10)
2.5 a 16
(12 a 6)
–, +1, +2 –
4.0 a 16
(12 a 6)
B1, B2 –
4.0 a 6.0
(12 a 10)
6.0
(10)
4.0 a 6.0
(12 a 10)
M5
2 a 2.5
(17.7 a 22.1)
4A0030
R/L1, S/L2, T/L3
10
(8)
6.0 a 16
(10 a 6)
M5
3.6 a 4.0
(31.8 a 35.4)
U/T1, V/T2, W/T3
10
(8)
6.0 a 16
(10 a 6)
–, +1, +2 –
6.0 a 16
(10 a 6)
B1, B2 –
6.0 a 10
(10 a 8)
M5
2.7 a 3.0
(23.9 a 26.6)
10
(8)
6.0 a 10
(10 a 8)
M6
4 a 6
(35.4 a 53.1)
