INSTALACIÓN (cont.)
Dimensiones exteriores
Classic 40
2.8 37.8
4xM20 2.8
30.1
41.3
4.8
6.9
5.1
10.0
5.1
25.8
DIA. 13.8
DIA. 22.0
10.0 20.7 12.9
43.5
5.1
10.2
4.3
6XM6
2X6XM6
22.4
1.9
2.3
8.9
8.9
3.9
DIA. 20.7
11.8 11.8
23.6
1.6 1.6
1.2
25.6
DIA. 0.6
Unidad: pulgadas
