APÉNDICE F – TORRE MONTÓN PC-104: POSICIONES DE LOS PUENTES
4
f-4
HD4070
Manual del operador
Bloque de puentes
Posición
Puente
JP1
1,2 puente
3
abierto
JP2
1,2 abierto
3,4 puente
5,6 abierto
JP3
1,2
puente
3
abierto
JP4
1,2 abierto
3,4 puente
5,6 abierto
JP5
13,14
puente
todos los demás abiertos
SW1
1
OFF
2,3,4
ON
5
ON
6,7,8
ON
48 Canal digital I/O #2 (B5)
Bloque de puentes
Posición
Puente
J2
1,2 puente
J4
1
abierto
2,3 puente
J5
1
abierto
2,3 puente
J6
1,2 abierto
3,4 puente
5,6 abierto
7,8 puente
J8
1,2 puente
3,4
puente
J7
todo abierto
Tablilla análoga (B6)
