Cybex 750T Treadmill Owner’s Manual
Specifi cations
Page A-1
Appendix A - Technical Specifi cations
Specifications
Length: 80” (204 cm).
Width: 34” (86 cm).
Running Area: 22” x 62” (56 cm x 157 cm).
Weight of Product: 410 lbs. (186 kg).
Shipping Weight 440 lbs. (200 kg).
Speed Range: 0.5 to 15.6 mph (0.8 to 25.1 kph) in 0.1 mph or 0.1 kph increments. Default Max Speed is
12.4 mph (20.0 kph).
Incline Range: -3 to 15% grade.
Manual Mode: Yes.
Programs: Quick Start plus Manual, Weight Loss, Rolling Hills, Hills, Pikes Peak, Hill Interval 1:1,
Hill Interval 1:2, Hill Interval 1:3, Cardio, HR Control, eight Fitness Tests and nine Custom
Programs.
Standard Features: Safety Sentry™, Contact Heart Rate, Polar ® wireless heart rate (chest strap not included),
CSAFE, frame color choices include white texture, black texture, metaltone gold, black chrome
and platinum sparkle.
Optional Features: Unlimited custom colors available.
Power Requirement: Grounded, single phase, dedicated line (discreet power and return for each circuit) and one of the
following:
• 100 VAC, 50/60 Hz, 20A.
• 115 VAC, 60 Hz, 20A.
• 220 VAC, 60 Hz, 15A. • 230 VAC, 50 Hz, 15A.
• 230 VAC, 50 Hz, 13A.
Motor: 3.0 hp Continuous, 6.0 hp Peak, AC, Brushless.
Emergency Stop: Pull the emergency stop key (e-stop).
Maximum User Weight: 400 lbs. (181 kg).
Options: Embedded A/V channel and volume controls and video mount bracket.
80” (204 cm)
34”
(86 cm)
