LISTA DE PIEZAS – ANTORCHA Y CONSUMIBLES
5-4
powermax1650
Manual de servicio
T100M Conjunto de antorcha mecanizada
Número
Artículo de pieza Descripción Cantidad
059265* T100M Machine Torch Assembly with 25 ft (7.6 m) Lead
059268* T100M Machine Torch Assembly with 35 ft (10.7 m) Lead
059272* T100M Machine Torch Assembly with 50 ft (15.2 m) Lead
1 128754 T100M Torch Main Body Replacement Kit 1
2 027889 Retaining Clip 1
3 058519 O-ring 1
4 128639 Cap-off Sensor Replacement Kit 1
5 075571 Cap-off Sensor Screws 2
6 128768 T100/T100M Torch Head Repair Kit 1
7 128643 Torch Mounting Sleeve Replacement Kit 1
8 075004 Torch Mounting Screws 3
9 128710 Torch Positioning Sleeve 1
10 128753 25 ft (7.6 m) Torch Lead Replacement Kit 1
11 128751 35 ft (10.7 m) Torch Lead Replacement Kit 1
12 128759 50 ft (15.2 m) Torch Lead Replacement Kit 1
13 128638 ETR Repair Kit (Regional Repair Centers only) 1
128645 Torch Mounting Kit (for reassembly after installation) 1
* El conjunto total incluye los siguientes consumibles: (Vea la página 5-6 para obtener más detalle sobre
consumibles).
220051 Swirl Ring 1
220037 Electrode 1
220011 Nozzle 1
220048 Retaining Cap 1
220047 Shield 1
