4.0 Mapa del Menú
SETUP
Estado/Falla
01 Remote Setup
01A Set Clock
11:18 AM
01D Power Save
15 Minute
01E Temp Display
Fahrenheit
01C Backlight
50 %
01B Contrast
100%
Set Clock
Hour = 11
:18 A
Set Contrast
0%
Set Backlight
0%
Set Power Save
OFF
Set Temp Display
Fahrenheit
Estado/Falla
02 Invert Setup
02A Search Watts
5 Watts
02C AC In – Time
6:00A to 6:00P
02B LBCO Setting
10.0 VDC
Set Search Watts
OFF
Set LowBatCutOut
Volts= 9.0
Set Connect
Hour = 6
:00 A
Rango: 12:00 a.m. a 11:59 p.m.
Rango: 0 a 100%
Rango: 0 a 100%
Rango: OFF, 1, 5, 10, 15, 30, 45, 60 Min
Rango: Fahrenheit o Celsius
Rango: OFF, 5 a 50 vátios
Rangos: 9,0 a 12,2
(12V)
, 18,0 a 24,4
(24V)
, 36 a 48,8
(48V)
Rango: 12:00 a.m. a 11:59 p.m.
Set Contrast
10%
Set Contrast
100%
....
Set Backlight
50%
Set Backlight
100%
....
Set Power Save
15 Minute
Set Power Save
60 Minute
....
Set Temp Display
Celsius
Set Search Watts
50 Watts
....
Set LowBatCutOut
Volts= 10.0
Set LowBatCutOut
Volts= 12.2
....
Set Connect
AM-PM =
6:00
A
Set Connect
Minute =
6:
00
A
Set Disconnect
Hour =
6:00
P
Set Disconnect
AM-PM =
6:00
P
Set Disconnect
Minute =
6:
00
P
Predeterminado: 100%
Predeterminado: 50%
Predeterminado: 15 Minute
Predeterminado: Fahrenheit
Predeterminado: 5 vátios
Predeterminado: 10VDC
(12V)
, 20VDC
(24V)
, 40VDC
(48V)
Predeterminado: 6:00 a.m. a 6:00 p.m.
S
S
S
S
S
S
S
S
S
S
El mapa del botón SETUP continúa en la próxima página
Set Clock
Minute =
11:
18
A
Set Clock
AM-PM =
11:18
A
S
S
Set Search Watts
5 Watts
S
S
S
S
S
....
....
....
Ilustración 4-2, Mapa del Menú del Botón SETUP
