83
Versión básica
Versión avanzada
Versión sencilla
ENGLISH DEUTSCH ESPAÑOL ITALIANO NEDERLANDS SVENSKA
Información
Especificaciones
n Sección de audio
• Amplificador de potencia
Salida nominal: Delantero:
100 W + 100 W (8 Ω, 20 Hz – 20 kHz con 0,08 % D.A.T.)
180 W + 180 W (6 Ω, 1 kHz con 10 % D.A.T.)
Central:
100 W (8 Ω, 20 Hz – 20 kHz con 0,08 % D.A.T.)
180 W (6 Ω, 1 kHz con 10 % D.A.T.)
Surround:
100 W + 100 W (8 Ω, 20 Hz – 20 kHz con 0,08 % D.A.T.)
180 W + 180 W (6 Ω, 1 kHz con 10 % D.A.T.)
Surround trasero:
100 W + 100 W (8 Ω, 20 Hz – 20 kHz con 0,08 % D.A.T.)
180 W + 180 W (6 Ω, 1 kHz con 10 % D.A.T.)
Conectores de salida: 6 – 8 Ω (SPEAKER A + B : 8 Ω)
• Analógico
Sensibilidad de entrada /
impedancia de entrada:
165 mV/50 kΩ
Frecuencia de respuesta: 10 Hz – 100 kHz — ±3 dB (Modo Source Direct)
S/N: 98 dB (IHF-A pesado, Modo Source Direct)
n Sección de vídeo
• Conectores de vídeo estándar
Nivel de entrada/salida e impedancia: 1 Vp-p, 75 Ω
Frecuencia de respuesta:
5 Hz – 10 MHz — +1, –3 dB
Frecuencia de respuesta:
• Conector de vídeo por componentes de
color
Nivel de entrada/salida e impedancia: Señal Y (luminosidad) — 1 Vp-p, 75 Ω
Señal P B / C B — 0,7 Vp-p, 75 Ω
Señal P R / C R — 0,7 Vp-p, 75 Ω
Frecuencia de respuesta: 5 Hz – 60 MHz — +0, –3 dB
n Sección de sintonizador [FM] [AM]
(Nota: μV at 75 Ω, 0 dBf = 1 x 10 –15 W)
Frecuencias de recepción: 87,5 MHz – 107,9 MHz 520 kHz – 1710 kHz
Sensibilidad útil: 1,2 μV (12,8 dBf) 18 μV
Sensibilidad de silenciamiento a 50 dB: MONO 2,8 μV (20,2 dBf)
S/R (IHF-A):
MONO 70 dB
STEREO 67 dB
Distorsión armónica total (a 1 kHz): MONO 0,7 %
STEREO 1,0 %
n General
Alimentación eléctrica: CA 120 V, 60 Hz
Consumo de energía: 650 W
0.2 W (modo de espera)
3 W (CEC modo de espera)
Dimensiones externas máximas: 440 (A) x 161 (A) x 389 (P) mm
Peso: 11,6 kg
n Mando a distancia (RC010SR)
Baterías: Tipo R03/AAA (dos baterías)
Con el propósito de introducir mejoras, las especificaciones y el diseño del equipo están sujetos a cambios
sin previo aviso.
Índice alfabético
v Numéricos
2.1-canales ··················································· 33, 36
3D ······································································· 14
5.1-canales ··················································· 33, 35
6.1-canales ··················································· 33, 34
7.1-canales ··············································· 4, 33, 34
v A
A2DP ···························································· 18, 78
Accesorios ···························································· 1
Adjust CH ··························································· 55
Adobe RGB color / Adobe YCC601 color ··········· 78
Altavoz
Conexión ······················································ 4, 34
Configuración ··············································· 6, 37
Instalación ···················································· 4, 33
Altavoz de altura frontal ································ 33, 34
Altavoz surround trasero ·························· 4, 33, 34
Amp Assign ························································ 56
Antena AM de cuadro ········································ 20
Antena interior de FM ········································ 20
Antenna Aiming ·················································· 47
Apagado (standby) ·············································· 11
ARC ···································································· 15
Aspect ································································ 50
Audio Adjust ······················································· 52
Audio Delay ························································ 55
Audio Setup ························································ 59
Audyssey Auto Setup ····································· 6, 37
Audyssey Dynamic EQ ································· 54, 78
Audyssey Dynamic Volume ························· 54, 78
Audyssey MultEQ ·································· 53, 69, 78
Audyssey Settings ············································· 53
Auriculares ························································· 69
Auto Lip Sync ··············································· 58, 78
Auto Preset ························································ 47
Auto Setup ····················································· 6, 37
v B
Base Curve Copy ················································ 55
Bass ····························································· 53, 59
Bass Setting ······················································· 57
Bluetooth ······················································ 18, 78
v C
Cable
Cable de audio ···························· 5, 16, 17, 18, 21
Cable de vídeo ······································ 16, 17, 18
Cable de vídeo por componentes ···············16, 17
Cable digital coaxial ····································16, 17
Cable HDMI ················································· 5, 15
Cable óptico ··············································· 16, 18
Cable para altavoz ·············································· 5
Caracteres ·························································· 45
Center Image ····················································· 52
Center Width ······················································ 52
Channel ······························································ 59
Channel Level ····················································· 58
Circuito de protección ········································ 78
Códigos preset ··················································· 63
Condensación ······················································· 2
Conexión
7.1CH INPUT ···················································· 21
Altavoz ························································· 4, 34
Amplificador de potencia externo ···················· 21
Antena ····························································· 20
Cable de alimentación ······································· 5
Cámara de vídeo digital ··································· 18
Consola de juego ············································· 15
DC OUT (TRIGGER OUT) ································· 38
Descodificador ············································15, 17
Dispositivo de memoria USB ··························· 19
HDMI ······························································· 14
iPod ·································································· 19
Receptor inalámbrico ······································· 18
REMOTE CONTROL ········································ 38
Reproductor de CD ·········································· 18
Reproductor de discos Blu-ray ··············· 5, 15, 16
Reproductor de DVD ·································· 15, 16
RS-232C ··························································· 38
Sintonizador de TV por satélite ························· 17
SIRIUS ····························································· 20
TV··························································· 5, 15, 16
TV por cable ····················································· 17
Videograbadora ················································ 17
Configuración del subwoofer ······························· 7
Control HDMI ····················································· 39
Conversión de vídeo ··········································· 13
Crossover Freq. ·················································· 58
v D
D.Comp ······························································ 52
DC Trigger ·························································· 61
Decode Mode ···················································· 50
Deep Color ··················································· 14, 78
Dimension ·························································· 52
Display ································································ 61
Distance ····························································· 57
Dolby
Dolby Digital··············································· 30, 78
Dolby Digital EX ········································· 30, 78
Dolby Digital Plus ······································· 30, 78
