APÉNDICE D – TABLA DE CONDICIÓN DE LA PANTALLA DE SERVICIO (#18)
0
d-2 HD4070 Manual del operador
Port 0 Base Addr 224H Output Port 1 Base Addr 225H Input Port 2 Base Addr 226H Output
Bit 0 Select 160 amp Pin 47 Bit 0 Input power active Pin 31 Bit 0 DC output On/Off Pin 15
Bit 1 Select 80 amp Pin 45 Bit 1 Missing phase detect Pin 29 Bit 1 Slave 160 amp select Pin 13
Bit 2 Select 40 amp Pin 43 Bit 2 Chopper #1 temp OK Pin 27 Bit 2 Slave 80 amp select Pin 11
Bit 3 Select 20 amp Pin 41 Bit 3 Chopper #2 temp OK Pin 25 Bit 3 Slave 40 amp select Pin 9
Bit 4 Select 10 amp Pin 39 Bit 4 Temp_Airflow_OK Pin 23 Bit 4 Slave 20 amp select Pin 7
Bit 5 Select 1_10 current/ cable
checkCout
Pin 37 Bit 5 Output current OK Pin 21 Bit 5 Slave 10 amp select Pin 5
Bit 6 Fan control Pin 35 Bit 6 Slave input power active Pin 19 Bit 6 Slave 1_10 current Pin 3
Bit 7 Contactor control Pin 33 Bit 7 Slave missing phase detect Pin 17 Bit 7 Slave fan control Pin 1
Port 3 Base Addr 220H Input Port 4 Base Addr 221H Output Port 5 Base Addr 222H Input
Bit 0 Slave Chopper #1 temp OK Pin 47 Bit 0 Slave contactor control Pin 31 Bit 0 Plasma interface spare input Pin 15
Bit 1 Slave Chopper #2 temp OK Pin 45 Bit 1 Slave DC output On/Off Pin 29 Bit 1 Master_door_interlock Pin 13
Bit 2 Slave_Temp_Airflow_OK Pin 43 Bit 2 Pump control Pin 27 Bit 2 Cable_checkA_in Pin 11
Bit 3 Slave current OK Pin 41 Bit 3 Torch #1 coolant Pin 25 Bit 3 Slave_door_interlock Pin 9
Bit 4 Spare input Pin 39 Bit 4 Torch #2 coolant Pin 23 Bit 4 Cable_checkC_in Pin 7
Bit 5 Transfer sense Pin 37 Bit 5 Spare out Pin 21 Bit 5 Gas_error Pin 5
Bit 6 Coolant flow switch Pin 35 Bit 6 Transfer 1 Pin 19 Bit 6 Spare_in4 Pin 3
Bit 7 Coolant temp switch Pin 33 Bit 7 Spare_out2 Pin 17 Bit 7 Spare_in19 Pin 1
Port 6 Base Addr 50H Ouput Port 7 Base Addr 51H Input Port 8 Base Addr 52H Input
Bit 0 Spare_out14 Pin 47 Bit 0 Spare_in1 Pin 31 Bit 0 Spare_in11 Pin 15
Bit 1 Spare_out15 Pin 45 Bit 1 Spare_in2 Pin 29 Bit 1 Spare_in12 Pin 13
Bit 2 Spare_out16 Pin 43 Bit 2 Spare_in3 Pin 27 Bit 2 Spare_in13 Pin 11
Bit 3 Spare_out17 Pin 41 Bit 3 Spare_in6 Pin 25 Bit 3 Spare_in14 Pin 9
Bit 4 Spare_out7 Pin 39 Bit 4 Spare_in7 Pin 23 Bit 4 Spare_in15 Pin 7
Bit 5 Spare_out8 Pin 37 Bit 5 Spare_in8 Pin 21 Bit 5 Spare_in16 Pin 5
Bit 6 Spare_out20 Pin 35 Bit 6 Spare_in9 Pin 19 Bit 6 Spare_in17 Pin 3
Bit 7 Spare_out21 Pin 33 Bit 7 Spare_in10 Pin 17 Bit 7 Spare_in18 Pin 1
Port 9 Base Addr 200H Output Port 10 Base Addr 201H Output Port 11 Base Addr 202H Output
Bit 0 Transfer 2 Pin 47 Bit 0 Pilot arc relay Pin 31 Bit 0 Gas_state1 Pin 15
Bit 1 Transfer 3 Pin 45 Bit 1 Surge injection select Pin 29 Bit 1 Gas_state2 Pin 13
Bit 2 Select 5 amp Pin 43 Bit 2 Spare_out13 Pin 27 Bit 2 Gas_state3 Pin 11
Bit 3 Select 2 amp Pin 41 Bit 3 THC1 cycle start Pin 25 Bit 3 Spare_out19 Pin 9
Bit 4 Watchdog_out Pin 39 Bit 4 THC2 cycle start Pin 23 Bit 4 CNC_transfer Pin 7
Bit 5 Slave 5 amp select Pin 37 Bit 5 Analog6_check_out Pin 21 Bit 5 CNC_motion Pin 5
Bit 6 Slave 2 amp select Pin 35 Bit 6 Cable_checkA_out Pin 19 Bit 6 THC1_corner_hold Pin 3
Bit 7 Cable_checkB_out Pin 33 Bit 7 Spare_out18 Pin 17 Bit 7 THC2_corner_hold Pin 1
Port 12 Base Addr 204H Input Port 13 Base Addr 205H Input Port 14 Base Addr 206H Output
Bit 0 THC1 Retract complete Pin 47 Bit 0 CNC corner hold Pin 31 Bit 0 CNC ready to fire Pin 15
Bit 1 THC1 Cable install Pin 45 Bit 1 CNC plasma sync Pin 29 Bit 1 CNC arc transfer Pin 13
Bit 2 THC1 Discrete error Pin 43 Bit 2 CNC emergency stop Pin 27 Bit 2 CNC machine motion Pin 11
Bit 3 THC2 Retract complete Pin 41 Bit 3 CNC machine cable installed Pin 25 Bit 3 CNC retract complete Pin 9
Bit 4 THC2 Cable installed Pin 39 Bit 4 CNC spare input Pin 23 Bit 4 CNC spare output Pin 7
Bit 5 THC2 Discrete error Pin 37 Bit 5 Watchdog_interlock Pin 21 Bit 5 CNC system error Pin 5
Bit 6 THC2 IHS complete Pin 35 Bit 6 THC1 IHS complete Pin 19 Bit 6 Serial Select1 Pin 3
Bit 7 CNC system start Pin 33 Bit 7 Cable_checkB_in Pin 17 Bit 7 Serial Select2 Pin 1
Serial Channels Addr 100H Analog Inputs Input
Com 1 Debug port 03F8H Channel Total current Pin 1
Com 2 Display serial 02F8H Channel Power Check Pin 2
Com 3 CNC Serial 03E8H Channel Not used Pin 3
Com 4 THC1/THC2 switched serial 02E8H Channel Not used Pin 4
Channel Not used Pin 7
Channel Not used Pin 8
Channel Analog6_check_in Pin 11
Channel Not used Pin 12
Tabla de condiciones de Entrada / Salida
La información que sigue es para búsqueda de averías por los técnicos de servicio. Si la terminología usada no es
conocida por el técnico, él debe ponerse en contacto con la Organización Europea de Apoyo Técnico, 800 49 73
7843 E-mail; Servicio Técnico en EE. UU., 800-643-9878 ([email protected]); o Hypertherm Brasil Ltda.,
55 21 2278 6162 ([email protected]).
