1009150 Rev. C 5
REF. NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
62
63
64
65
PART NO.
R-2251-10
R-2254-10
R-2270-10
R-1946
B-5924
11M0808P
2M1012P
B-1673P
B-4786
R-2415-10
R-2288
R-2289
R-2293-1
R-2416
R-2321
F-577
R-2205
50M0624P
R-2281
R-2259
R-2261
R-2262
R-2263
R-2485LH
R-2485RH
B-4768
R-2265-BT
R-2280
R-2293-2
R-2306-01
R-2413-10
45M1111P
B-4107
R-2296-10
R-2290-10
B-3805
2M1024P
2M1028P
30M1000P
40M1000P
B-3861
D-146P
R-1882
B-3307-S
2M1040P
30M1200P
B-1675P
B-983
R-2303
R-2304
R-618
R-1806-10
R-2194-10
R-2195
R-2426
R-2300-10
R-2301-10
R-2307
R-2320
11M1024P
2M1036P
R-2463
L-1744-4
DESCRIPTION
Hitch Clevis Assembly
Tow Tube
Lift Handle
Instruction Decal
Logo Decal
Carriage Bolt, ¼" x ½"
Hex Bolt, 5/16" x ¾"
Hex Lock Nut, ¼"
Nylon Insert Lock Nut, 5/16"
Lower Pivot Assembly
Bearing Assembly
Bearing Retainer
Inner Dust Shield
Lift Link
Self-Taping Screw #12x3/8"
"E" Ring, 5/8"
Brush Section
Cotter Pin, 3/16" x 1-1/2"
Brush Holder
Brush Axle
Dowel Pin
Washer, 5/8" I.D. x 1-3/8
Washer, 5/8" I.D. x 7/8"
Drive Pinion, Left Hand
Drive Pinion, Right Hand
5/8" Machinery Bushing
Wheel, 12" x 3" Bar Trd.
Drive Gear, 60 Tooth
Outer Gear Cover
Wheel Axle
Brush Housing Assembly
5/16" Flat Washer
Vinyl Cap, 1" dia.
Hamper Stop Assembly
Upper Frame Assembly
Spring
Hex Bolt, 5/16" x 1-1/2"
Hex Bolt, 5/16" x 1-3/4"
Hex Nut, 5/16"
Lock Washer, 5/16"
Hitch Pin, ½" dia.
Hairpin Cotter, Large
Flat Grip
Lock Pin
Hex Bolt, 5/16" x 2-1/2"
Hex Nut, 3/8"
Lock Nut, 3/8"
Hairpin Cotter, Small
Clevis Pin, 5/16" x 1-3/8"
Hamper Pull Rope
Special Washer, 5/16"
Lower Tube
Rear Tube
Hamper Stop Rod
Hamper/Wind Screen
Hamper Side Tube, Upper
Hamper Mount Tube
Hamper Spring Rod
External Retaining Ring, 5/8"
Carriage Bolt,5/16"x 1-1/2"
Hex Bolt, 5/16" x 2-1/4"
Adjustment Label
Serial Number Label
QTY.
1
2
1
1
1
6
4
6
9
1
2
2
2
1
4
6
6
4
4
1
2
2
2
1
1
4
2
2
2
2
1
3
2
1
1
1
2
1
1
1
1
1
1
1
2
2
2
2
2
1
4
2
2
1
1
2
2
2
2
4
2
1
1
66 1008997 Pull Handle 1
67 1009049 Adhesive Hook & Loop 1
PARTS LIST
53
53 56
56
52
52
9
51
57
33
45
58 58
47
55
50
46
54
66
67
