3.5 Setup Address: MIDI Section
Sys-EX Parameters Address MSB/LSB (HEX)
Byte Value (HEX)
Category Parameter MAIN SUB1 SUB2 SUB3
Buttons Part Switch 04/3C 04/74 05/2C 05/64 1 00,01 (Off , On)
1. Ch/Prog. MIDI Transmit Channel 04/3D 04/75 05/2D 05/65 1 00-0F (1~16Ch)
PGM Change Number 04/3E 04/76 05/2E 05/66 1 00-7F (1~128)
Bank Number MSB 04/40 04/78 05/30 05/68 1 00-7F (0~127)
Bank Number LSB 04/3F 04/77 05/2F 05/67 1 00-7F (0~127)
2. SETUP
3. Transmit
4. MMC
*undefi ned - - - - - -
5. KeySetup Touch Mode 00/47 1 0-2 (Normal, Off -Fast, Off -Fast2)
Touch Curve 04/46 04/7E 05/36 05/6E 1
00-0A (Heavy+, Heavy, Normal,
Light, Light+, Off , Sys.User1~5)
Octave Shift 04/4B 05/03 05/3B 05/73 1 3D-40-43 (-3~0~+3)
Zone Transpose 04/4C 05/04 05/3C 05/74 1 34-40-4C (-12~0~+12)
Key Range - Zone Low 04/42 04/7A 05/32 05/6A 1 15-6C (A-1 ~ C7)
Key Range - Zone High 04/43 04/7B 05/33 05/6B 1 15-6C (A-1 ~ C7)
Velo SW 04/44 04/7C 05/34 05/6C 1 00-02 (Off , Loud, Soft)
Velo SW Value 04/45 04/7D 05/35 05/6D 1 0-7F
KS-Damping 04/4E 05/06 05/3E 05/76 1 00,01 (Off ,On)
KS-Key 04/4D 05/05 05/3D 05/75 1 15-6C (A-1 ~ C7 )
Dynamics 04/47 04/7F 05/37 05/6F 1 00,01-0A (Off , 1-10)
Solo On/Off 04/49 05/01 05/39 05/71 1 00,01 (Off , On)
Solo Mode 04/4A 05/02 05/3A 05/72 1 00-02 (Last, High, Low)
Transmit *undefi ned - - - - - -
6. Control Damper Pedal On/Off 04/50 05/08 05/40 05/78 1 00,01 (Off , On)
Damper Pedal Assign 00/34 1 00-77,78 (CC#0-119, AfterTouch)
Half Pedal Value 04/6B 05/23 05/5B 06/13 1 00-7F
PitchBend Wheel On/Off 04/57 05/0F 05/47 05/7F 1 00,01 (Off , On)
PitchBend Range 04/58 05/10 05/48 06/00 1 00-0C
Modulation Wheel On/Off 04/55 05/0D 05/45 05/7D 1 00,01 (Off , On)
Modulation Wheel Assign 04/56 05/0E 05/46 05/7E 1 00-77,78 (CC#0-119, AfterTouch)
Right Pedal On/Off 04/51 05/09 05/41 05/79 1 00,01 (Off , On)
Right Pedal Assign 00/35 1 00-77,78 (CC#0-119, AfterTouch)
Center Pedal On/Off 04/52 05/0A 05/42 05/7A 1 00,01 (Off , On)
Center Pedal Assign 00/36 1 00-77,78(CC#0-119, AfterTouch)
Left Pedal On/Off 04/53 05/0B 05/43 05/7B 1 00,01 (Off , On)
Left Pedal Assign 00/37 1 00-77,78 (CC#0-119, AfterTouch)
EXP Pedal On/Off 04/54 05/0C 05/44 05/7C 1 00,01 (Off , On)
EXP Pedal Assign 00/38 1 00-77,78 (CC#0-119, AfterTouch)
7. KnobAsgn KnobA Assign (1/2) 04/5B 05/13 05/4B 06/03 2 00-77,78 (CC#0-119, AfterTouch)
KnobB Assign (1/2) 04/5C 05/14 05/4C 06/04 2 00-77,78 (CC#0-119, AfterTouch)
KnobC Assign (1/2) 04/5D 05/15 05/4D 06/05 2 00-77,78 (CC#0-119, AfterTouch)
KnobD Assign (1/2) 04/5E 05/16 05/4E 06/06 2 00-77,78 (CC#0-119, AfterTouch)
KnobA Assign (2/2) 04/5F 05/17 05/4F 06/07 2 00-77,78 (CC#0-119, AfterTouch)
KnobB Assign (2/2) 04/60 05/18 05/50 06/08 2 00-77,78 (CC#0-119, AfterTouch)
KnobC Assign (2/2) 04/61 05/19 05/51 06/09 2 00-77,78 (CC#0-119, AfterTouch)
KnobD Assign (2/2) 04/62 05/1A 05/52 06/0A 2 00-77,78 (CC#0-119, AfterTouch)
