3.4 Setup Address: Internal Section
(cont.)
Category Parameter
Address MSB/LSB (HEX)
Byte Value (HEX)
MAIN SUB1 SUB2 SUB3
3. Sound Volume 01/37 02/5B 02/7F 05/23 1 0-7F
Panpot 01/38 02/5C 04/00 05/24 1 0-40-7F (L64~0~R63)
Cutoff 01/39 02/5D 04/01 05/25 1 0-40-7F (-64~0~+63)
Resonance 01/3A 02/5E 04/02 05/26 1 0-40-7F (-64~0~+63)
DCA Attack Time 01/3B 02/5F 04/03 05/27 1 0-40-7F (-64~0~+63)
DCA Decay Time 01/3C 02/60 04/04 05/28 1 0-40-7F (-64~0~+63)
DCA Sustain Level 01/3D 02/61 04/05 05/29 1 0-40-7F (-64~0~+63)
DCA Release Time 01/3E 02/62 04/06 05/2A 1 0-40-7F (-64~0~+63)
DCF Attack Time 01/3F 02/63 04/07 05/2B 1 0-40-7F (-64~0~+63)
DCF Attack Level 01/40 02/64 04/08 05/2C 1 0-40-7F (-64~0~+63)
DCF Decay Time 01/41 02/65 04/09 05/2D 1 0-40-7F (-64~0~+63)
DCF Sustain Level 01/43 02/67 04/0B 05/2F 1 0-40-7F (-64~0~+63)
DCF Release Time 01/42 02/66 04/0A 05/2E 1 0-40-7F (-64~0~+63)
DCF Touch Depth 01/44 02/68 04/0C 05/30 1 0-40-7F (-64~0~+63)
DCA Touch Depth 01/45 02/69 04/0D 05/31 1 0-40-7F (-64~0~+63)
Vibrato Depth 01/46 02/6A 04/0E 05/32 1 0-40-7F (-64~0~+63)
Vibrato Rate 01/47 02/6B 04/0F 05/33 1 0-40-7F (-64~0~+63)
Vibrato Delay 01/48 02/6C 04/10 05/34 1 0-40-7F (-64~0~+63)
Octave Layer On/Off 01/49 02/6D 04/11 05/35 1 00,01 (Off , On)
Octave Layer Level 01/4A 02/6E 04/12 05/36 1 0-7F
Octave Layer Range 01/4B 02/6F 04/13 05/37 1 3D-40-43 (-3~+0~+3)
Octave Layer Detune 01/4C 02/70 04/14 05/38 1 0-40-7F (-64~0~+63)
Portament SW 01/4D 02/71 04/15 05/39 1 00,01 (Off ,On)
Portament Time 01/4E 02/72 04/16 05/3A 1 0-7F
Portament Mode 01/4F 02/73 04/17 05/3B 1 00,01 (Rate, Equal)
Drawbar 16’ Level 01/50 - - - 1 0-7F
Drawbar 5 1/3’ Level 01/51 - - - 1 0-7F
Drawbar 8’ Level 01/52 - - - 1 0-7F
Drawbar 4’ Level 01/53 - - - 1 0-7F
Drawbar 2 2/3’ Level 01/54 - - - 1 0-7F
Drawbar 2’ Level 01/55 - - - 1 0-7F
Drawbar 1 3/5’ Level 01/56 - - - 1 0-7F
Drawbar 1 1/3’ Level 01/57 - - - 1 0-7F
Drawbar 1’ Level 01/58 - - - 1 0-7F
Percuss On/Off 01/59 - - - 1 00,01 (Off ,On)
Percuss Level 01/5A - - - 1 00,01 (Normal,Soft)
Percuss Decay 01/5B - - - 1 00,01 (Slow,Fast)
Percuss Harmonic 01/5C - - - 1 00,01 (2nd,3rd)
4. Tuning Fine Tune 00/7B 02/1F 03/43 04/67 1 0-40-7F (-64~0~+63)
Stretch Tuning 00/7C 02/20 03/44 04/68 1 00-08 (Off , Narrow2, Narrow1, Normal, Wide1, Wide2~5)
Temperament 00/7D 02/21 03/45 04/69 1
00-08 (Equal, PureMaj, PureMin, Pythagor,
Meantone, Werkmeis, Kirnberg, Sys. User1~2)
Temperament Key 00/7E 02/22 03/46 04/6A 1 00-0B (C~B )
5. KeySetup Touch Mode 00/47 1 0-2 (Normal, Off -Fast, Off -Fast2 )
Touch Curve 01/04 02/28 03/4C 04/70 1 00-0A (Heavy+,Heavy,Normal,Light,Light+,Off ,Sys.User1~5)
Octave Shift 01/09 02/2D 03/51 04/75 1 3D-40-43 (-3~0~+3)
Zone Transpose 01/0A 02/2E 03/52 04/76 1 34-40-4C (-12~0~+12)
Key Range - Zone Low 01/00 02/24 03/48 04/6C 1 15-6C (A-1 ~ C7 )
Key Range - Zone High 01/01 02/25 03/49 04/6D 1 15-6C (A-1 ~ C7 )
Velocity Switch 01/02 02/26 03/4A 04/6E 1 0-2 (Off , Loud, Soft)
Velocity Switch Value 01/03 02/27 03/4B 04/6F 1 0-7F
KS-Damping 01/0C 02/30 03/54 04/78 1 00,01(Off ,On)
KS-Key 01/0B 02/2F 03/53 04/77 1 15-6C (A-1 ~ C7 )
Dynamics 01/05 02/29 03/4D 04/71 1 00,01-0A (Off ,1-10)
Solo 01/07 02/2B 03/4F 04/73 1 00,01 (Off ,On)
Solo Mode 01/08 02/2C 03/50 04/74 1 0-2 (High, Low, Last )
