Hypertherm Powermax1650 Rev.1 - Manual (Página 81)

MANTENIMIENTO Y PIEZAS
powermax1650
Manual del operador 5-11
Accesorios
Piezas de la fuente de energía
128788 Stationary mounting kit
128647
011092
Optional air filtration kit
Replacement filter for optional air filtration kit
027668 Plasma cutting guide – deluxe
127102 Plasma cutting guide – basic
027684 Replacement bushing for the plasma cutting guide assembly
127100 Powermax1650 dust cover
123655 50 ft (15M) work cable with clamp and strain-relief
023206 CNC interface cable
220049 Gouging heat shield for hand torch
128650 On/off pendant for machine torch, 25 ft (7.5 m)
128651 On/off pendant for machine torch, 50 ft (15 m)
128652 On/off pendant for machine torch, 75 ft (22.9 m)
024548 Leather torch lead sheathing
128888 FineCut kit: Powermax1000/1250/1650
128889 FineCut kit: Powermax1000/1250/1650 CE
804470 Powermax1650 service manual
128740 Cover assembly, CSA (14 screws included)
128762 Cover assembly, CE (14 screws included)
075533 Cover screws (Individual cover screw)
128627
011092
Air filter bowl with fittings
Replacement filter element
129654 ETR door assembly
129405 Consumable box
123654 20 ft ground clamp with cable and strain-relief
128750 Kit: Powermax1650 labels, CSA
128758 Kit: Powermax1650 labels, CE
