XXXXXXXX © CANON INC. 2015
2
ESPAÑOL
1. Download setup file. 2. Select connection method.
Select a printer connection method and click Next .
Follow the on-screen instructions to proceed the
setting.
When the screen below appears, the printer is
ready to use.
Click
Next to continue installing the software.
3. Install software.
When the screen below appears, select the
software you want to install and click Next .
Follow the on-screen instructions to proceed the
setting.
Now your computer is connected to
printer.
a Access the following URL in your web browser. Windows PC users: you can also
open the file from the setup CD-
ROM.
The screen in h will appear when
you open the file from the CD-
ROM. Perform the remaining steps
in the same way as on the website.
Select the same method as you did in
Getting Started 1 .
Wireless LAN Connection
Connect the printer to a network without any
cables.
Wired LAN Connection
Connect the printer to a network with an
Ethernet cable.
USB Connection
Connect the printer to your computer with a
USB cable. This is the easiest way. You only
can connect one printer.
b Click Set Up .
c Select the region where you purchased the product.
d Select your product.
e Click Connecting to Computer, Smartphone or Tablet .
f Select your operating system.
g Click Download to download the setup file.
* If a download security warning appears, allow your web
browser to continue downloading.
h Open the downloaded file and click Start Setup .
i Follow the on-screen instructions to proceed the setup.
You can connect the printer to a PC/smartphone/tablet and install software.
Have you finished all the steps in the Getting Started 1 ?
Please read this manual after completing the printer setup in the
Getting Started 1 .
NOTE
ENGLISH
Using wireless router
Not using/having wireless router
/
When wired LAN connection is selected
in Getting Started 1:
Proceed to connect printer to
• Did you select wireless LAN connection in Getting Started 1 ?
• Did you select wired LAN connection in Getting Started 1 ?
• Using wireless router
• Not using/having wireless router
(Connecting printer to device via wireless LAN
connection directly)
* If you connect your device to the printer via wireless LAN connection directly, you
may be unable to access the Internet with your device or may be charged for an
Internet connection.
Turn on Wi-Fi on your smartphone or tablet before you start.
This procedure is for when the printer has been connected to a wireless router with an Ethernet
cable in Getting Started 1 . Your smartphone or tablet must be connected to a wireless router via
Wi-Fi.
2. Check your network configuration.
1. Install Canon PRINT Inkjet/SELPHY to your
smartphone/tablet.
Proceed to right side.
Smartphone or
Tablet
PC
* This procedure is described based on Canon PRINT Inkjet/SELPHY 2.2.0. In other versions, follow
the application instructions to complete the setup.
: Search "Canon PRINT" in App Store.
: Search "Canon PRINT" in Google Play.
Or access the website by scanning the code on the right. Getting Started 2
a Tap Settings
on the home
screen.
a Tap Settings
on the home
screen.
c Tap PRINT which
was installed.
c Tap PRINT which
was installed.
b Tap Canon_ij_XXXX on the Wi-Fi setting.
b Tap Canon_ij_XXXX on the Wi-Fi setting.
If Canon_ij_XXXX does not appear on the list, see NOTE
to setup the printer and wait until Canon_ij_XXXX appears.
XXXX varies depending on your printer.
The extended
survey screen
appears on the
first startup.
The extended
survey screen
appears on the
first startup.
If Canon_ij_XXXX does not appear on the list, see NOTE
to setup the printer and wait until Canon_ij_XXXX appears.
XXXX varies depending on your printer.
The license
agreement screen
appears on the
first startup.
If the screen in b does
not appear, see NOTE
to setup the printer and
wait until the screen
appears.
If none of these screens appears, see "If Select Router
screen appears".
If the printer is not
detected and an error
message appears on
the printer, press the OK
button and start over from
a .
If the printer is not detected and
an error message appears on the
printer, press the OK button and
start over from a .
d Tap the printer icon
on the top left of the
screen.
d Tap the printer icon
on the top left of the
screen.
h Tap OK . i Select the SSID of your
wireless router connected
to your device.
j When a password entry
screen appears, enter
the password for your
wireless router and tap
OK .
k Wait for a while until the
printer is detected.
l When the printer is
detected, tap your
printer's model name.
m Enter the printer name
as needed and tap
OK .
n When the printer
information appears
on the screen, the
setup is complete.
e Tap Register Printer .
e Tap Register Printer .
f Tap Printer Setup .
f Tap Printer Setup .
g Tap Connect via
wireless router
(recommended) .
g Tap Direct
Connection .
j Tap Settings on
the home screen.
m Tap PRINT . h Tap OK . i Check the SSID and password
and tap Copy Password .
o Wait for a while until the
printer is detected.
n Tap Done . k Tap the same SSID as
checked in i .
l Paste the password
and tap Join .
p When the printer is detected, tap
your printer's model name.
q Enter the printer name as
needed and tap OK .
r When the printer information
appears on the screen, the
setup is complete.
If Canon_ij_XXXX does not appear:
If a message saying " Printer is not registered. Perform printer setup? " does not appear at Canon PRINT
Inkjet/SELPHY startup:
Do the following on the printer.
a Press the OK button. c Go back to Canon PRINT Inkjet/
SELPHY and start over from a in
/ / .
b Select Cableless setup and
press the OK button.
When you start up Canon PRINT Inkjet/SELPHY, the printer is detected
automatically. See - l to perform the remaining steps.
When you start up Canon PRINT Inkjet/SELPHY, a dialog asking you to
setup a printer appears.
The printer will be detected by following the on-screen instructions. See
- e to perform the remaining steps.
a Tap PRINT
which was
installed.
b Tap Yes .
Make sure the SSID
of the desired wireless
router appears and tap
Yes .
Enter the password of
the wireless router and
tap OK .
Tap Yes . Tap OK .
Do the following if this screen appears.
• When the SSID of the desired wireless router
appears, tap it.
Make sure your device is connected to the
same SSID.
• If the SSID of the desired wireless router does
not appear or you are not sure, tap If no target
wireless router .
If Select Router screen appears:
c Follow the on-screen instruction. d Wait for a while
until the printer is
detected.
e When the printer is
detected, tap your
printer's model name.
f Enter the printer
name as needed and
tap OK .
g When the printer
information appears
on the screen, the
setup is complete.
PC (Windows/Mac OS)
Smartphone/Tablet (iOS/Android)
Do the following if the screen in a does not appear.
1. Press the Setup button to display the Setup menu screen.
2. Select Wireless LAN setup and press the OK button.
3. Select Cableless setup and press the OK button, and then proceed to c above.
QT6-1245-V01 PRINTED IN XXXXXXXX
