FIORINA103 S-LINE
ITEM DESCRIPTION
UM
QUANTITY
CODE
1
LEFT SIDE PANEL
NR
1
420582
2
SMOKE EXTRACTOR PL21CE0180
NR
1
43020800
3
STAINLESS STEEL PIPE
NR
1
420112
4
LEFT BRACKET TANK
NR
1
420583
5
BODY STOVE
NR
1
420500
6
RIGHT BRACKET TANK
NR
1
420584
7
BLACK TOP COVER
NR
1
420585
8
DISPLAY SUPPORT
NR
1
420586
9
DISPLAY
NR
1
411301
10
INSULATION RING FOR AUGER
NR
1
414196
11
PELLET TUBE
NR
1
420587
12
ELECTRIC HEATER 270W 230V X 6-8KW
NR
1
410010H
13
AIR CARTER
NR
1
420588
14
PELLET TANK
NR
1
420562
15
REAR PANNEL
NR
1
420589
16
MAIN PCB SUPPORT
NR
1
420590
17
POWER SUPPLY
NR
1
410011
18
PCB J042
NR
1
410615
19
THERMOSTAT 100°C LS16025516 2.5A T85
NR
1
410009
20
AUGER
NR
1
410015
21
BUSHING FOR AUGER
NR
2
410065
22
HOLDING AUGER
NR
1
410056
23
GEAR MOTOR MEM390 230/50/2RPM
NR
1
410006
24
AUGER SUPPORT
NR
1
420574
25
AUGER TUBE SUPPORT
NR
1
420591
26
RIGHT SIDE PANEL
NR
1
420592
27
CENTRIFUGAL FAN
NR
1
411188N
28
AIR CARTER FOR CENTRIFUGAL FAN
NR
1
420602
29
DIFFERENTIAL AIR PRESSURE SWITCH
C6065A1002:2 0,6-6MBAR
NR
1
410007H
30
BASEMENT STOVE
NR
1
420563
31
INSIDE FUND
NR
2
420593
32
CAST IRON BRAZIER
NR
1
411687
33
ASH BOX
NR
1
420514
34
ASH GRATE
NR
1
420594
35
RIGHT INTERNAL WALL
NR
1
420514
36
RIGHT ALUMINIZED PLATE
NR
1
420512
37
FRAME DOOR
NR
1
420598
38
HANDLE
NR
1
420599
39
LEFT ALUMINIZED PLATE
NR
4
420513
40
AIR GRILLE
NR
1
420600
41
FLAME SHIELD
NR
1
420511
42
LEFT INTERNAL WALL
NR
1
420596
43
SPACER FOR FAN
NR
1
420602
Ø
GRID TANK
NR
1
410150
Ø
BURNER BOX
NR
1
420601
Ø
PELLET DOOR
NR
1
420604
Ø
GLASS 205X413MM SP.4MM
NR
1
410639
Ø
DOOR FRAME
NR
1
420548
Ø
ADJUSTABLE FEET
NR
4
410023
Ø
FLAT CABLE FOR DISPLAYER
NR
1
410238
Ø
CABLING
NR
1
420001
Ø
REMOTE CONTROL
NR
1
411673
Ø
SMOKE SENSOR SONK1000ACCA
NR
1
411307
Ø
ROOM SENSOR STUFA
NR
1
410240
Ø
DOOR SEAL DIAM 14MM
ML
1,4
410020
Ø
GLASS SEAL 15X3MM
ML
1,3
410029
Ø
USER MANUAL
NR
1
001162
Ø
INSTALLATION MANUAL
NR
1
001163
FIORINA103 S-LINE - SPARE PARTS LIST
Ø particolare non rappresentato nell'esploso.
