113
FIORINA74 FIORINA90
ITEM DESCRIPTION UM Quantity Code Code
1 ELECTRIC HEATER 270W 230V X 6-8KW NR 1 410010H 410010H
2 AUGER SUPPORT NR 1 43020800 43020800
3 PCB J042 NR 1 410615 410615
4 THERMOSTAT 100°C LS16025516 2.5A T85 NR 1 410009 410009
5 POWER SUPPLY NR 1 410011 410011
6
DIFFERENTIAL AIR PRESSURE SWITCH
C6065A1002:2 0,6-6MBAR
NR 1 410007 410007
7 TANGENTIAL FAN NR 1 410004T 410004T
8 MAIN PCB SUPPORT NR 1 419006 419006
9 REAR PANNEL NR 1 419005 419005
10 PELLET TANK NR 1 419700 419700
11 AIR CARTER NR 1 43020700 43020700
12 GRID TANK NR 1 410149 410149
13 GEAR MOTOR MEM390 230/50/2RPM NR 1 410006 410006
14 AUGER NR 1 410015 410015
15 BUSHING FOR AUGER NR 2 410065 410065
16 DISPLAY SUPPORT NR 1 43102000 43102000
17 DISPLAY NR 1 411301 411301
18 BODY STOVE NR 1 - -
19 REMOTE CONTROL NR 1 411673 411673
20 BLACK TOP COVER NR 1 43102200 43102200
21 LEFT BRACKET TANK NR 1 419004 419004
22 STAINLESS STEEL PIPE NR 1 420112 420112
23 SIDE PANEL (BORDEAUX/GREY) NR 2 4310700B/G 43105800B/G
24 SMOKE EXTRACTOR PL21CE0180 NR 1 410694 410694
25 SEAL SMOKE EXTRACTOR NR 1 419900 419900
26 CENTRAL INTERNAL WALL NR 1 419405 419405
27 FLAME SHIELD NR 1 419407 419407
28 LEFT INTERNAL WALL NR 1 419406 419406
29 LEFT ALUMINIZED PLATE NR 1 419404 419404
30 AIR GRILLE NR 1 419009 419009
31 DOOR (ASSEMBLED) NR 1 43106600 43106700
31 GLASS 205X413MM SP.4MM NR 1 410639 410639
32 HANDLE NR 1 43102908 43102908
33 RIGHT ALUMINIZED PLATE NR 1 419403 419403
34 RIGHT INTERNAL WALL NR 1 419406 419406
35 CAST IRON BRAZIER NR 1 411688 411688
36 ASH BOX NR 1 419001 419001
37 BURNER BOX NR 1 43020900 43020900
38 LEFT INSIDE FUND NR 1 43020601 43020601
39 RIGHT INSIDE FUND NR 1 43020602 43020602
40 BASEMENT STOVE NR 1 - -
41 ADJUSTABLE FEET NR 4 410023 410023
42 PELLET FEEDER NR 1 43020200 43020200
43 ELECTRIC HEATER TUBE NR 1 419300 419300
44 RIGHT BRACKET TANK NR 1 419003 419003
Ø FLAT CABLE FOR DISPLAYER NR 1 410238 410238
Ø CABLING NR 1 411380 411380
Ø SMOKE SENSOR SONK1000ACCA NR 1 411307 411307
Ø ROOM SENSOR STUFA NR 1 410240 410240
Ø DOOR SEAL DIAM 14MM ML 1,4 410020 410020
Ø GLASS SEAL 15X3MM ML 1,3 410029 410029
Ø USER MANUAL NR 1 001160 001160
Ø INSTALLATION MANUAL NR 1 001161 001161
FIORINA74 - FIORINA90 - SPARE PARTS LIST & PRICES
Ø particolare non rappresentato nell'esploso.
