298 9469372991 Rev A
Legacy Register Table DGC-2020HD Protocolo Modbus ™
Registro Descripción Tipo Unidades
Factor de
escala
R/W Intervalo
44964-65 Bits de estados de entradas remotas Int32 n/d n/d R Bit 0 = No se usa
Bit 1 = No se usa
Bit 2 = No se usa
Bit 3 = No se usa
Bit 4 = No se usa
Bit 5 = No se usa
Bit 6 = No se usa
Bit 7 = No se usa
Bit 8 = No se usa
Bit 9 = No se usa
Bit 10 = No se usa
Bit 11 = No se usa
Bit 12 = No se usa
Bit 13 = No se usa
Bit 14 = No se usa
Bit 15 = No se usa
Bit 16 = No se usa
Bit 17 = No se usa
Bit 18 = No se usa
Bit 19 = No se usa
Bit 20 = No se usa
Bit 21 = No se usa
Bit 22 = Entrada remota 26
Bit 23 = Entrada remota 25
Bit 24 = Entrada remota 24
Bit 25 = Entrada remota 23
Bit 26 = Entrada remota 22
Bit 27 = Entrada remota 21
Bit 28 = Entrada remota 20
Bit 29 = Entrada remota 19
Bit 30 = Entrada remota 18
Bit 31 = Entrada remota 17
44966-67 Bits de estados de salidas remotas Int32 n/d n/d R Bit 0 = No se usa
Bit 1 = No se usa
Bit 2 = No se usa
Bit 3 = No se usa
Bit 4 = No se usa
Bit 5 = No se usa
Bit 6 = No se usa
Bit 7 = No se usa
Bit 8 = Salida remota 36
Bit 9 = Salida remota 35
Bit 10 = Salida remota 34
Bit 11 = Salida remota 33
Bit 12 = Salida remota 32
Bit 13 = Salida remota 31
Bit 14 = Salida remota 30
Bit 15 = Salida remota 29
Bit 16 = Salida remota 28
Bit 17 = Salida remota 27
Bit 18 = Salida remota 26
Bit 19 = Salida remota 25
Bit 20 = Salida remota 24
Bit 21 = Salida remota 23
Bit 22 = Salida remota 22
Bit 23 = Salida remota 21
Bit 24 = Salida remota 20
Bit 25 = Salida remota 19
Bit 26 = Salida remota 18
Bit 27 = Salida remota 17
Bit 28 = Salida remota 16
Bit 29 = Salida remota 15
Bit 30 = Salida remota 14
Bit 31 = Salida remota 13
