010297 REVA
CAUTION
Fill Coolant Reservoir with Hypertherm Coolant
! Hypertherm Nr. 028393 Liquide De Refroidisseur Remplir Le Reservoir Avec
ATTENTION
! 010177 REVA Part No. 028393
CAUTION
AVERTISSEMENT
WARNING
R
H
PE
Y
ON l
-TRANSFORMER -COOLANT LEVEL -SHIELD GAS/CAP -PLASMA GAS -COOLANT TEMP -COOLANT FLOW
0
R
E
H
T
R
M
OFF 0
DC ON
AMPS 2
0
POWER
MACHINE DELAY
3
6 SEC
0
-INTERLOCK STATUS
TEST
RUN
PLASMA
100 60
40
20 O ZE R
80
GAS
SHIELD 40
20 ZE R O
80
60 100
CAUTION
15
APÉNDICE A – COMPATIBILIDAD ELECTROMAGNÉTICA (EMC)
a-6 MAX200 (Soplete mecanizado) Manual del operador
Lista de piezas del filtro emi
Ref. Número Descripción Cantidad
001557 Cover: 200/2000-CE Electronic Filter Enclosure 1
1 001558 Enclosure: 200/2000-CE Electronic Filter 1
2 001559 Cover: 200/2000-CE Top 1
3 008489 Bushing: 1.97 ID X 2.5 Hole Black-Snap 1
4 008610 Strain Relief: 1-1/2NPT 1.5ID 2-Screw 1
5 029316 TB1 Input-Power SA: 200/2000/4X00/HD 1
6 109036 Filter: 60A 440VAC 3PH 2-Stage Electronic 1
7 109040 Filter Mounting Bracket for 109036 1
Figura a-4 Piezas del filtro EMI MAX200
3
1
5
4
2
6 7
