20
49-2000682 Rev. 0
ENGLISH
CARE AND CLEANING
OVEN LIGHT
WARNING
SHOCK OR BURN HAZARD: Before
replacing oven light bulb, disconnect the electrical power to
the range at the main fuse or circuit breaker panel. Failure to
do so may result in electric shock or burn.
CAUTION
BURN HAZARD: The glass cover and bulb
should be removed when cool. Touching hot glass with bare
hands or a damp cloth can cause burns.
Oven Light Replacement
NOTE: The glass cover should be removed only when cold.
Wearing latex gloves may offer a better grip.
Before replacing the bulb, disconnect electrical power to the
oven at the main fuse or circuit breaker panel. Let the bulb
cool completely before removing it. For your safety do not
touch a hot bulb with a damp cloth. If you do the bulb may
break.
To remove:
Turn the glass cover counterclockwise 1/4 turn until the tabs
of the glass cover clear the grooves of the socket and pull
the cover off. Remove the bulb.
To replace:
Put in a new 40-watt appliance bulb. Place the tabs of the
glass cover into the grooves of the socket. Turn the glass
cover clockwise 1/4 turn.
NOTE:
• A 40-watt appliance bulb is smaller than a standard
40-watt household bulb.
• Reconnect electrical power to the oven once the new bulb
is installed.
• For improved lighting inside the oven, clean the glass
cover frequently using a wet cloth. This should be done
when the oven is completely cool.
OVEN DOOR
The door is very heavy. Be careful when removing and lifting
the door. Do not lift door by the handle.
To Remove the Door:
1. Fully open the door.
2. Pull the hinge locks up and away from the range frame to
the unlocked position.
3. Firmly grasp both sides of the door near the top.
4. Close door until the top of the door is approximately 6”
from the range frame.
5. Lift door up and away from the range until both hinge
arms are clear of the slots in the range frame.
To Replace the Door:
1. Firmly grasp both sides of the door near the top.
2. With the door at the same angle as the removal position,
rest the notch on the underside of the left hinge arm on
the bottom edge of the left hinge slot. The notch in the
hinge arm must be fully seated into the bottom of the
slot. Repeat for the right side.
3. Fully open the door. If the door will not fully open, the
notches in the bottoms of the hinge arms have not
seated correctly in the bottom edge of the slot. Lift the
door off the range and repeat previous step.
4. Push the hinge locks toward the range cavity and down
to the locked position.
5. Close the oven door.
Push hinge locks down to lock Rest notch on bottom edge
of hinge slot
Notch
Bottom
edge of
slot
Hinge arm
Removal position Pull hinge locks up to unlock
Bulb
Socket
Tab
3 1 \ 2
”
Max
length
Glass cover
