KayakDD – Mezclador Digital de Producción
7.5.2 Comandos GVG200 Soportados
Nombre Código Comando Comentarios
TRANSITION MODE COMMAND CA Solo se soporta Escritura:
TRANSITION RATE COMMAND CC/CD Solo se soporta Escritura:
TRANSITION PUSHBUTTON
SELECT COMMAND
FB
CROSSPOINT BUS COMMAND
C1-C4
(C1-CF for aux)
41-44
(41-4F for aux)
Crosspoint interpretation:
GVG code
Interpretation
01H...0x14 INPUT 1...20
15H ME1 OUT
16H ME2 OUT
17H CLEAN FEED
18H MAIN OUT
21H ME3 OUT
25H...27H COLOR BGD 1...3
30H...4BH INPUT 21...48
Aux busses:
The number of Aux Busses in not limited.
If the effect address is 07H (= Aux Crosspoint) the lower nibble of the
command code will be interpreted as the AUX bus number.
So up to 15 Aux Busses can be controlled.
PUSHBUTTON COMMAND
C6
(C7 for REV,KEY CUT
keyer 1, KEY CUT
keyer 2)
Solo se soportan: MIX ,WIPE, REV y KEY CUT.
MIX and WIPE will switch the currently selected buttons for next transition to
the given state.
WIPE PATTERN SELECT
COMMAND
C8 Solo se soporta Escritura:
ALL STOP COMMAND F2
LEARN E-MEM REGISTER DA
RECALL E-MEM REGISTER DB
NOTA!
El GVG “DSK“ se traducirá por el DD35 “PP“.
Sincronización:
Se utiliza el protocolo estándar GVG200: Los comandos se ejecutaran en el tercer
campo después de la respuesta
