Cybex 11010 Eagle Overhead Press - Manual (Página 5)

Manual del propietario de Cybex
5
Advertencias y precauciones
Las etiquetas de advertencia indican una situación potencialmente peligrosa, que si no se evita, puede provocar lesiones
graves o la muerte.
Las etiquetas de precaución indican una situación potencialmente peligrosa que, si no se evita, puede provocar lesiones
leves o moderadas.
Las etiquetas de advertencia y precaución se muestran en la página siguiente. Los diagramas que aparecen con las
etiquetas indican el lugar en el que está colocada cada etiqueta.
